Murata 2XS Wi-Fi + BLUETOOTH module
2023-03
Power
Murata
[Mar 25 2023] The Murata 2XS Wi-Fi + Bluetooth module is a small high-performance module based on the NXP 88W9098 chipset. The 88W9098 chipset supports Wi-Fi 802.11a/b/g/n/ac/ax 2x2 MIMO + Bluetooth 5.3 BR/EDR/LE 2MPHY. The Murata 2XS Wi-Fi + Bluetooth modules are 2.5GHz and 5GHz modules with PHY data rates up to 1200Mbps on Wi-Fi and 3Mbps on Bluetooth. The 2XS includes an embedded reference clock with PCIe/S ...
Universal dual operational amplifier
2023-03
Semiconductors
STMicroelectronics
[Mar 25 2023] The stmicroelectronics TSB621 Low Power op-amp is a general-purpose dual op-amp with an extended operating supply voltage range (2.7V to 36V) and rail-to-rail output. The TSB621 has an excellent speed/power ratio with a gain bandwidth of 1.7MHz and power consumption of less than 375μA per operator when powered at 36V. Operating temperatures range from -40°C to +125°C, the SOT23-5 packaged TSB621 ...
Two-way TV diodes provide a typical 0.3pF capacitance
2023-03
Power
Littelfuse
[Mar 25 2023] Littelfuse AQ31xE-01ETG two-way TV diodes offer typical 0.3pF capacitance, 1nA leakage current, and 18V or 28V reverse stand-off voltage ratings. These diodes offer ultra-low capacitance, a two-way design, and a high level of protection for electrical equipment that is vulnerable to destructive electrostatic discharge (ESD). Low capacitance ratings help ensure excellent signal integrity even on t ...
TE Connectivity / AMP Connectors AMP Micro CT Connectors
2023-03
Power
TE Connectivity
[Mar 24 2023] The AMP Micro CT connector is designed to provide an economical line routing solution for power or signal needs. These connectors provide impressive performance in their harness-making capabilities. AMP MicroCT connectors feature IDC terminals, discrete wire interconnects and AWG 26 to 28 cable sizes. These CT connectors offer a wide range of configurations, with circuits ranging from 2-25 single ...
Taoglas Universe PCS.60.A Low-Profile SMD Antenna
2023-03
Power
Taoglas
[Mar 24 2023] Taoglas Universe personal Computer. The Low-Profile SMD antenna is an active cellular and GNSS antenna designed for Internet of Things devices with small ground planes. PCS.60. The antenna combines aperture tuning and active switching technologies to provide broadband coverage for GNSS and most 5G/4G LTE cellular bands, including the challenging 600MHz to 700MHz bands. The antenna is easy to inte ...
Taoglas Bolt A.85 Permanent-Mount Antenna
2023-03
Optoelectronics
Taoglas
[Mar 24 2023] The Taoglas Bolt A.85 Permanently Mounted antenna is a high-gain GNSS L1/L5 (GPS/GLONASS/Galileo/Beidou) antenna with a low profile, damage resistant design. The antenna has high out-of-band suppression and handles high-power bursts from nearby transmitters, allowing continuous operation. a. The 85 L1/L5 GNSS permanently mounted antenna uses an efficient patch antenna that optimizes performance w ...
NXP Semiconductor S32G Vehicle Network Processing Evaluation Committee
2023-03
Semiconductors
NXP
[Mar 24 2023] The NXP Semiconductor S32G Vehicle Network Processing Evaluation Board 3 is designed for vehicle service-oriented gateways (SOGs), domain control applications, high-performance processing, and safety and security applications. The evaluation board provides a combination of automotive and enterprise networking technologies that provide multiple interfaces to the vehicle network. The S32G eval boar ...
Nonlinear front end module
2023-03
Power
Qorvo US Inc.
[Mar 24 2023] The Qorvo QPF4617 Wi-Fi 6E Nonlinear front-end module is designed for Wi-Fi 6E (802.11ax) systems. The Qorvo QPF4617 is designed to be used in conjunction with DPD correction. The device features a smaller contour size and integrated matching that minimizes application layout area. Performance is focused on optimizing the PA efficiency of the 5V supply voltage, minimizing power consumption. This ...
Temperature compensated crystal oscillator (TCXO)
2023-03
Power
ECS
[Mar 23 2023] ECS ECS-TXO-TX20CSMV4 MultiVolt Temperature Compensated Crystal Oscillator (TCXO) provides 1.7V to 3.6V MultiVolt capability and stabilizes critical applications using analog compensation. These shear sine wave SMD TCXOs are compatible with 1.8V, 2.5V, or 3.3V power supplies and offer frequency ranges from 10MHz to 52MHz, 10KΩ/10pF output loads, ±1ppm frequency tolerance, and ±0.5ppm or ±1.5ppm f ...
16-bit Sigma-Delta ADC
2023-03
Semiconductors
Analog Devices
[Mar 23 2023] Analog Devices AD4129-8 16-Bit Sigma-Delta Analog-to-Digital Converter (ADC) is an ultra-low power high-precision measurement solution for low bandwidth battery-operated applications. The fully integrated analog front end (AFE) includes a multiplexer for up to 16 single-ended or eight differential inputs, a programmable gain amplifier (PGA), and 16-bit sigma-delta (Σ-Δ) ADC, on-chip reference and ...
Analog Devices provide power amplifiers
2023-03
Semiconductors
Analog Devices
[Mar 23 2023] Analog Devices ADPA7002 power amplifier is a Gallium arsenide (GaAs), pseudocrystalline High electron mobility transistor (pHEMT), monolithic microwave integrated circuit (MMIC), 28dBm (1/2W) amplifier. A 6mm x 6mm ceramic leadless chip with a heat sink (LCC_HS) provides low thermal resistance and is compatible with surface mount manufacturing techniques. The ADPA7002 integrates a temperature com ...
Low Voltage Differential Signal (LVDS) Temperature Compensated Crystal Oscillator (TCXO)
2023-03
Power
ECS
[Mar 23 2023] The ECS ETXO-L33CL ECSpressCON Low Voltage Differential Signal (LVDS) temperature compensated Crystal Oscillator (TCXO) has low jitter, low current and a typical supply voltage of 3.3V. These surface mount oscillators are available in a frequency range of 10MHz to 1500MHz, with input currents of 25mA to 36mA, and package sizes of 3.2mm x 2.5mm x 1.6mm. Additional features include frequency config ...
