Technology Articles

2023-03 Optoelectronics Skyworks Solutions

[Mar 20 2023] The Skyworks Solutions SI8585x-KIT evaluation suite provides a demonstration and development platform for the Si858x integrated isolated RS-485 transceiver. These devices combine powerful, fully compatible RS-485 transceivers with signal isolation. The Si858x transceiver is an ideal choice for industrial automation applications, requiring a fieldbus system with isolated interfaces to form a commu ...

2023-03 Power Panduit Corp

[Mar 20 2023] The PANJIT MBR5H60PC-AU Schottky Block rectifier is a surface-mounted ultra-low reverse current (IR) rectifier with a maximum cyclic peak reverse voltage of 60V. The rectifier also has 5A maximum average forward rectifier current, low leakage current, low power loss, high efficiency and high surge current capabilities. The MBR5H60PC-AU Schottky Block rectifier is certified by AEC-Q101, in complia ...

2023-03 Power Linear Technology/Analog Devices

[Mar 20 2023] The LT1175 is a negative micropower low drop voltage regulator. Available in 8-pin PDIP and SO packages, 3-pin SOT223 and 5-pin surface-mounted DD and through-hole TO-220 packages. The 8-pin SO package is designed for low thermal resistance. It has a static current of 45μA, which drops to 10μA when turned off. A new reference amplifier topology provides precise DC characteristics and the ability ...

2023-03 Optoelectronics Maxim Integrated

[Mar 20 2023] Maxim Integrated MAX25255 Synchronous step-down converter is a dual step-down converter with integrated high side and low side switches. Maxim IC provides up to 8A current per channel and input voltage ranges from 3V to 36V. These devices consume only 12μA static current when unloaded. Voltage quality can be monitored by observing the PGOOD signal. The MAX25255 adjusts the output voltage in the d ...

2023-03 Power Maxim Integrated

[Mar 19 2023] MAX9984 High linearity down-conversion mixer offers 8.1dB gain, +25dBm IIP3 and 9.3dB NF for base station receiver applications from 400MHz to 1000MHz *. The mixer features an optimized 570MHz to 850MHz LO frequency range, which is well suited to the low side LO injection receiver architecture in the cellular band. The MAX9986 supports high-side LO injection, which is pin-to-pin and is functional ...

2023-03 Power Renesas Electronics America

[Mar 19 2023] The ISL9000 is a high-performance dual LDO capable of 300mA current from each output source. It has a low standby current and high PSRR, output capacitance stability of 1µF to 10µF with the ESR is as high as 200 mΩ. The device integrates a separate power-on reset (POR) function for each output. The POR delay of VO2 can be externally programmed by connecting the timing capacitor to the CPOR pin. T ...

2023-03 Power Broadcom

[Mar 19 2023] The HCFC-T250 contains GaAs leds. The LED is optically coupled to an integrated circuit with a power output stage. The optical coupler is ideal for use in motor control inverter applications with drive power IGBTs and MOSFets. The high operating voltage range of the output stage provides the drive voltage required by the gated device. The voltage and current provided by this optical coupler make ...

2023-03 Semiconductors ON Semiconductor

[Mar 19 2023] The NCT75 is a dual-wire series programmable temperature sensor with an overtemperature/interrupt output pin to signal beyond the limits. This is a leak-open pin that works in comparator or interrupt mode. Temperature measurements are converted to digital form using a high resolution (12-bit)sigma-delta analog-to-digital converter (ADC). The operating temperature range of the device is -55°C to + ...

2023-03 Power Analog Devices

[Mar 19 2023] The LTC6811 is a multi-cell stack monitor that measures up to 12 cells connected in series with a total measurement error of less than 1.2mV. The 0V to 5V battery measurement range makes the LTC6811 suitable for most battery chemicals. All 12 units can be measured in 290µs, and low data acquisition rates can be selected for high noise reduction. Multiple LTC6811 devices can be connected in series ...

2023-03 Optoelectronics Amphenol ICC (FCI)

[Mar 18 2023] Ampherol Commercial Ve-NET Automatic multi-gigabit connector system can transmit 1000Mb/s to 10Gb/s based on 1000BASE-T1, 10GBASE-T1, and 50GBASE-CR. The connector system uses shielded twisted pair/shielded parallel cable to transmit data. The entire system was developed according to USCAR-2, LV214, and Ethernet specifications. The Ve-NET connector system makes sound when fitting, avoiding mismat ...

2023-03 Power Microchip Technology

[Mar 18 2023] The MCP73827 is a linear charge management controller for space-limited, cost-sensitive applications. The input voltage ranges from 4.5V to 5.5V. MCP73827 is fully specified in the ambient temperature range from -20°C to +85°C. The MCP73827 combines high precision constant voltage, controlled current regulation, battery pretreatment, and charging status indication in a space-saving 8-pin MSOP pac ...

2023-03 Semiconductors STMicroelectronics

[Mar 18 2023] The STMicroelectronics SM50TxAY 5000W Transient Voltage Suppressor (TVS) is packaged in SMC and is designed to protect sensitive automotive circuits from surges as defined in ISO 7637-2. These voltage suppressors also protect sensitive automotive circuits from electrostatic discharge and meet ISO 10605 standards. The SM50TxAY series transient Voltage suppressors are suitable for use in electronic ...
