Technology Articles

2023-03 Semiconductors Microchip Technology

[Mar 1 2023] Microchip Technology PL460 programmable narrowband PLC modem designed to run any PLC protocol in bands below 500kHz. The PL460 is embedded with PLC line drivers for a highly integrated solution that reduces gross bill of materials, simplifies layout and simplifies modem design. Microchip PL460 PLC modems meet FCC, ARIB, KN60, and CENELEC EN50065 regulatory matching requirements for Internet of Th ...

2023-03 Semiconductors Nexperia

[Mar 1 2023] The Nexperia NCA9555PW 16-bit I2C and SMBus I/O expander is an efficient solution that extends the general-purpose input/Output (GPIO) functionality of I2C bus /SMBus applications. The Nexperia NCA9555PW device has a wide operating voltage range of 1.65V to 5.5V. The NCA9555 is designed to meet the needs of a variety of devices, including interrupt and pull-up resistors. These devices include ACP ...

2023-03 Semiconductors Texas Instruments

[Mar 1 2023] The Texas Instruments OPA593 Precision Operational Amplifier is a high voltage (85V), high precision, wide bandwidth (10MHz), high output current (250mA), unit-gain stable, power operational amplifier. The OPA593 uses laser trimming technology to improve offset voltage (20µV, typical) and offset voltage temperature drift (0.4µV/°C, typical), thus no calibration is required. The device has a multi ...

2023-02 Semiconductors Texas Instruments

[Feb 28 2023] Texas Instruments TPS7A43 Low Voltage Drop (LDO) linear regulators incorporate input voltage ranges of 4V to 85V and ultra-low static current features. This device supports a wide range of input voltages (e.g., 15-cell batteries and 24V to 48V line power supplies) and can withstand line transient voltages up to 85V. These features help modern applications meet increasingly demanding energy requir ...

2023-02 Sensors Eaton - Electronics Division

[Feb 28 2023] The Eaton EXLA1V08 Automotive High current Molded Inductor is a magnetically shielded inductor with low electromagnetic interference (EMI), low DC resistance (DCR), and high current-carrying capability. These molded inductors have an inductance range of 3.3μH to 10μH, A current range of 8.7A to 20A, and soft saturation. The EXLA1V08 inductor comes in a 9.2mm x 8.8mm x 8.0mm surface mount package ...

2023-02 Semiconductors Texas Instruments

[Feb 28 2023] Texas Instruments TPS38700/TPS38700-Q1 Power Sequence generator is a multi-channel voltage sequence generator with integrated window watchdog in a 24-pin 4mm x 4mm VQFN package. The TPS38700/TPS38700-Q1 is designed for use in systems requiring precise power-on and/or power-off timing and can be connected to multi-channel voltage monitors. By default, the sort generator uses the pre-programmed OTP ...

2023-02 Semiconductors Analog Devices

[Feb 28 2023] Analog Devices Inc. ADRF5023 Single pole double throw (SPDT) silicon switch is a non-reflective single pole double throw (SPDT) switch manufactured by silicon process. The ADRF5023 has an operating frequency range of 9kHz to 45GHz, 1.7dB insertion loss typical value and 42dB isolation. The switch has RF input power processing capabilities of 30dBm (through path), 24dBm (end path) and 30dBm (RF co ...

2023-02 Optoelectronics TE Connectivity

[Feb 28 2023] TE Connectivity's (TE) CGS RLW73 wide-end current detection resistor features a reliable multilayer electrode construction with long-side terminals and a high purity alumina substrate for high power consumption. The series offers up to 3W of high power in the 1225 configuration, with resistance values ranging from 10mΩ to 750mΩ. These resistors are wide-ended variants of the RL73 series. The wide ...

2023-02 Semiconductors Diodes Incorporated

[Feb 27 2023] Diotec Semiconductor MMFTP2319 P-channel enhanced mode FET provides fast switching times in SOT-23/TO-236 packages. The MMFTP2319 FET has a maximum drain-source voltage of 40V, a maximum power consumption of 750mW, and a maximum drain current of 4.2A in the junction temperature range from -50°C to +150°C. Diotec Semiconductor MMFTP2319 p-channel enhanced mode FETs are ideal for signal processing, ...

2023-02 Semiconductors Nexperia

[Feb 27 2023] The Nexperia PSMN1R9 and PSMN2R3 n-channel mosfeTs are designed for ultra-high performance and reliability. The Nexperia PSMN device is part of the Nexperia application-specific MOSFET (ASFET) family. These MosFeTs are specifically designed for hot-swap and soft-start applications and operate at temperatures up to 175°C. With low RDSon and enhanced safe workspace performance, these devices are id ...

2023-02 Sensors Omron Electronics Inc-EMC Div

[Feb 27 2023] Omron Electronics G9KA-E Power relay with ≤0.2mΩ ultra low contact resistance, very low heat generation on PCB. These relays are rated higher than standard G9KA at 1000VAC and 300A, and their terminals are carefully designed to achieve higher heat dissipation radiation and maintain low temperatures. The unique dual braking and dual contact structure ensures lower contact resistance, while the col ...

2023-02 Optoelectronics TE Connectivity

[Feb 27 2023] TE Connectivity (TE) Kemtron Aluminum honeycomb air vents are designed to provide high shielding performance and good airflow by directing electromagnetic waves into or out of the housing through tubes used as waveguides. Single layer aluminum honeycomb foil with high impact ABS UL 94V-0 flame retardant frame, therefore light weight, cost-effective. Designed for use with 40mm, 60mm, 80mm, 92mm an ...
