Technology Articles

2023-03 Semiconductors Navitas Semiconductor, Inc.

[Mar 3 2023] Navitas Semiconductor GaNFast Power integrated circuits are easy to use, high speed, high performance "digital input, power output" building blocks. The component features integrated grid drive, wide range VCC and PWM inputs, internal 2kV ESD protection and large thermal cooling pads. Monolithic integrated drivers and power stages achieve high switching frequencies while keeping the signal clean ...

2023-03 Optoelectronics E-Switch

[Mar 3 2023] E-Switch TD1250 Detector switch is SPST-NOs, supplied with PCB or solder lug terminal. These switches are available in 8.25mm x 5.25mm x 11.70mm housing, with multiple drive options including pin plungers, straight levers, and S-shaped levers. The contact material is silver and the TD1250 detector switch provides 160gf driving force. The TD1250 series offers contact ratings of 1mA, 5VDC to 50mA, ...

2023-03 Power Texas Instruments

[Mar 3 2023] Texas Instruments TPS543A26 Synchronous Step-Down Converter is a 16A synchronous SWIFT converter with internally compensated advanced current mode. The converter has a working input voltage range of 4V to 18V and an output voltage range of 0.5V to 7V. The TPS543A26 converter provides high efficiency with switching frequencies up to 2.2MHz. Therefore, the device is well suited for use in designs r ...

2023-03 Power Texas Instruments

[Mar 3 2023] Texas Instruments INA232 Current/Voltage/Power Monitor is a 16-bit digital current monitor with an I2C/SMBus compatible interface. Compatible with a wide range of digital bus voltages such as 1.2V, 1.8V, 3.3V, and 5.0V, the device also monitors voltage across external detection resistors and reports current, bus voltage, and power values. The INA232 has programmable ADC conversion time and averag ...

2023-03 Semiconductors Analog Devices

[Mar 3 2023] Analog Devices LTC3306 synchronous step-down voltage regulator is a very small, high efficiency, low noise, monolithic synchronous step-down DC/DC converter that can provide 1.75A (maximum) average output current through 2.25V to 5.5V input power supply. Adopt 6-pin 1.6mm × 1 mm, 0.5 mm spacing WLCSP package. These regulators adopt a compact solution size with constant frequency, peak current mod ...

2023-03 Sensors MEAN WELL

[Mar 2 2023] MEAN WELL DDRH-120 and DDRH-240 DIN rail DC-DC converters have an ultra-wide input range of 250 VDC to 1500VDC, high isolation level of 4kVAC, fanless design, and operating temperature range of -40°C to +80°C. These 120W/240W units have excellent EMC performance, operate at high altitudes of 5000M, and comply with IEC/EN 62109-1 PV safety standards. Both series have comprehensive protection featu ...

2023-03 Semiconductors Texas Instruments

[Mar 2 2023] The Texas Instruments TPSI3052-Q1 Enhanced Switch driver is a fully integrated device that, when combined with an external power switch, constitutes a complete isolated solid-state relay (SSR). The switch driver is an integrated isolation protection device that provides robust functionality with higher reliability, lower power consumption, and a wider temperature range. The TPSI3052-Q1 Switch dri ...

2023-03 Semiconductors Texas Instruments

[Mar 2 2023] Texas Instruments TPSM82816 DC/DC Power modules are based on the fixed frequency peak power mode control topology. The power module is an efficient, easy to use synchronous DC/DC step-down power module with integrated inductors, pin-to-pin compatible 3A, 4A, and 6A. The TPSM82816 module can operate in the adjustable frequency range of 1.8MHz to 4MHz and can be synchronized to the external clock i ...

2023-03 Sensors STMicroelectronics

[Mar 2 2023] The STMicroelectronics VL53L8CX 8x8 Multi-zone time-of-flight sensor improves performance in ambient light and reduces power consumption. The VL53L8CX is based on ST's FlightSense technology and is designed to provide accurate ranging up to 400cm with a 65° diagonal FoV. VL53L8CX can measure absolute distances regardless of target color and reflectance. The VL53L8CX integrates a powerful new gene ...

2023-03 Semiconductors Analog Devices

[Mar 2 2023] Analog Devices Inc. EVAL-ADuM4195-1EBZ Evaluation Board is a compact isolated DC voltage monitoring board designed to evaluate the characteristics of the ADUM4195-1. The ADUM4195-1 has very low misalignment and gain error and is suitable for many isolation voltage detection applications. The ADI EVAL-ADuM4195-1EBZ board provides two independent inputs. The P1000 input is pre-configured to accept ...

2023-03 Optoelectronics MEAN WELL

[Mar 1 2023] MEAN WELL RQB40W12 and RQB150W3 DC-DC converters with 2KVAC/3KVAC high isolation voltage achieve high efficiency in quarter brick packaging. These DC-DC converters feature an ultra-wide input range and a wide operating temperature range from -40°C to 90°C. RQB40W12 and RQB150W3 DC-DC converters comply with railway standard EN50155 and provide remote on/off control and remote detection. These DC-D ...

2023-03 Power Swissbit

[Mar 1 2023] The Swissbit N4200 PCIe Gen 4.0 SSD provides adequate storage capacity for consistent high performance and low latency. The Swissbit N4200 measures workloads and performs analysis to configure firmware. This process allows you to customize the storage method to ensure optimal performance for web, streaming media, applications, and cache servers. With firmware optimized to match workload profiles, ...
