Technology Articles

2023-02 Semiconductors Infineon Technologies

[Feb 27 2023] Infineon Technologies EZ-PD PMG1-B1 USB Type-C High-voltage Microcontroller (MCU) is a highly integrated single-port USB-C power supply (PD) solution with integrated step-up controller. These controllers have integrated grid drivers for VBUS NFets on consumption paths in current filling applications, in addition to hardware control protection features on the VBUS. EZ-PD PMG1-B1 supports voltages ...

2023-02 Power KEMET

[Feb 26 2023] KEMET Electronics AEC-Q200 compliant metal composite inductors have up to 50G vibration resistance in a shielded construction and SMD configuration. These inductors use a metal composite core with high saturation capacity to maintain normal function under high current transients. The metal composite core has a temperature-stable inductance, whereas inductors that comply with the AEC-Q200 standard ...

2023-02 Semiconductors Pulse Electronics

[Feb 26 2023] The Pulse Electronics Outdoor Radome Omnidirectional (RO) antenna is designed for use in harsh outdoor environments with excellent mechanical stability. These antennas have UV protection and IP67 protection rating, ensuring long life, reliability and maintenance-free. These outdoor radome antennas have a 20W power rating, 2:1 VSWR, and a gain range of 3.4dBi to 10dBi. These antennas are available ...

2023-02 Power Weidmuller

[Feb 26 2023] The Weidmiller IE-SR Dual SIM Industrial Router with integrated VPN technology is ideal for secure remote access to components and systems in remote networks. These secure routers feature 4G/LTE modules, WLAN, two RJ45 Ethernet ports, and a serial interface for maximum connectivity. The IE-SR security router is compact and can save space in the control cabinet. These industrial security routers i ...

2023-02 Semiconductors Diodes Incorporated

[Feb 26 2023] Diotec Semiconductor DI020N06D1 N-channel power MosFets have low on-off resistance, low gate charge (25.3nC), and fast switching times with avalanche ratings. These components provide 60V drain-source breakdown voltage, 20A continuous drain-source current, and 24 Mω drain-source resistance in the operating temperature range from -55°C to +175°C. The TO-252AA encapsulated DI006H03SQ mosfet is suit ...

2023-02 Semiconductors Diodes Incorporated

[Feb 26 2023] Diodes Incorporated DSCxA065/DSCxC065 SIC Schottky diodes have excellent reverse leakage current stability at high temperatures. These Schottky diodes comply with the AEC-Q100/101/104/20 standard and have PPAP capability. DSCxA065/DSCxC065 Schottky diodes have low on-off and switching losses, fast reverse recovery, and high surge current capabilities. These Schottky diodes operate in temperatures ...

2023-02 Optoelectronics Wurth Electronics

[Feb 25 2023] WurthuElektronik offers a variety of Ethernet solutions, including LAN transformers and modular jack connectors. The WE-LAN transformer series is designed with at least one transformer per channel and a common mode choke. The LAN transformer portfolio includes Power over Ethernet (PoE) up to 150W with speeds up to 1Gbit/s WE-LAN series, 10G Base-T and PoE(+) four pairs of We-Lans transmitting pow ...

2023-02 Optoelectronics IQD Frequency Products

[Feb 25 2023] IDEC HW1B Plastic Baffle E-Stop button provides 600V rated insulation voltage, 10A rated thermal current, tamper-proof construction. These switches feature IP20 protected finger safe contact blocks and include illuminated and non-illuminated buttons, indicator lights, select switches and emergency stop switches. HW1B series switches include lock bar detachable contact blocks and are available wit ...

2023-02 Power Allegro MicroSystems, LLC

[Feb 25 2023] The Allegro MicroSystems ATS19480 Giant Magnetoresistance (GMR) transmission speed Sensor IC provides a user-friendly, two-wire solution for applications using ferromagnetic gear tooth targets requiring speed information. Fully integrated components include the GMR IC, protective capacitors for EMC stability, and rear bias magnets in a single inline lead-free 3-pin SIP package with additional mol ...

2023-02 Power Microchip Technology

[Feb 25 2023] Microchip Technology PIC16F18054/55/74/75 Microcontroller (MCU) is a compact and feature-rich device with powerful analog and digital peripherals. These microcontrollers feature 128-byte data flash memory (EEPROM), 7KB/14KB program flash memory, 512 byte /1024 byte data SRAM, and 32MHz clock input. The PIC16F180x microcontroller also has a 1.8V to 5.5V operating voltage range and a 125ns minimum ...

2023-02 Semiconductors Infineon Technologies

[Feb 25 2023] The Infineon XMC7000 32-bit Industrial Microcontroller is a low-power 40nm process MCU that delivers outstanding computing performance for high-end industrial applications. The XMC7000 MCU is based on the XMC portfolio and offers higher computing performance, as well as dual-core options, larger memory, support for sleep mode and hardware security. The device is equipped with peripherals such as ...

2023-02 Power Monolithic Power Systems Inc.

[Feb 24 2023] Monolithic power System (MPS) MCS1806 Hall Effect current sensor is a 3kVRMS isolated current sensor with an operating voltage of 500VRMS and an accuracy of ±2.5%. These linear Hall effect current sensors for AC or DC current transducers combine differential Hall arrays to cancel out any stray magnetic fields. The working principle involves a primary conductor with low resistance that allows curr ...
