Technology Articles

2023-03 Power Analog Devices

[Mar 15 2023] Analog Devices' LT3154 High Performance Step-boost DC/DC converter is a 6A low noise, high efficiency, high current, step-boost DC/DC converter that operates from an input voltage above, below, or equal to the regulated output voltage. Is a simple solution that requires minimal external components. The advanced topology provides continuous transmission through operational modes. VIN operation fro ...

2023-03 Semiconductors STMicroelectronics

[Mar 15 2023] The NUCLEO-H563ZI STM32 Nucleo-144 plates are an affordable and flexible way to experiment with a wide range of performance and power characteristics. NUCLEO-H563ZI is equipped with internal or external SMPS that greatly reduce power consumption in operating mode, making it ideal for sustainable projects. The ST Zio connector and ST morpho head make it easy to function as an expansion board, with ...

2023-03 Semiconductors Analog Devices

[Mar 15 2023] The Matt Isolated Flyback controller is a micro power isolated flyback controller with 390μA (active mode) low static current. These controllers drive low-side n-channel power mosFeTs with 8V grid drivers that operate in a wide input voltage range of 4.5V to 60V. These LT8306 flyback controllers are AEC-Q100 certified devices in a 6-pin ThinSOT package. The LT8306 flyback controller samples the i ...

2023-03 Power Renesas Electronics America

[Mar 15 2023] The Renesas Electronics RA6E2 microcontroller is designed for high performance applications in a compact package. Renesas Electronics RA6E2 features a 200MHz Arm® Cortex®-M33 core, 256KB code flash memory, and 40KB SRAM. These devices have a variety of peripherals and safety features optimized for increased efficiency and performance. These 40nm process microcontrollers are ideally suited to meet ...

2023-03 Semiconductors Sensirion AG

[Mar 15 2023] Sensirion SFM6000D Mass Flow Controllers are valve-less SFC6000 mass flow controller variants. The Sensirion SFM6000D offers performance at a low price. The controllers are small, lightweight, and ideal for optimizing the size and weight of portable devices. With excellent repeatability,accuracy, control range, and speed, this highly integrated controller is built using CMOSens MEMS technology. F ...

2023-03 Power Texas Instruments

[Mar 14 2023] Texas Instruments OPT4048 Trichromatic XYZ Color Sensor is a single-chip high-resolution color sensor capable of measuring four channels, each with a specific designed spectral response. Three of the four channels closely match the CIE tricolor spectrum, and the fourth channel has a wideband spectral response. By taking measurements from these channels, important properties of the lighting enviro ...

2023-03 Sensors Renesas Electronics America Inc.

[Mar 14 2023] The Renesas Electronics RA4E2 microcontroller features a 100MHz Arm® Cortex®-M33 core, 128KB code flash memory, and 40KB SRAM for extremely high performance. Renesas Electronics RA4E2 features a variety of peripherals, such as universal PWM timer, 12-bit ADC, 12-bit Dacs, USB FS devices, SCI, SPI, I3C, SSI, and HDMI-CEC. The device is ideal for low memory, small package, low pin number applicatio ...

2023-03 Power Renesas Electronics America

[Mar 14 2023] Renesas Electronics RA4E2 Evaluation Suite provides a comprehensive platform for testing and evaluating the functionality of RA4E2 microcontrollers. The Renesas Electronics RA4E2 kit enables engineers to explore the full capabilities of the RA4E2. Compatible with Flexible software packages (FSPS), the suite further simplifies the evaluation process and facilitates testing and validation of design ...

2023-03 Semiconductors Texas Instruments

[Mar 14 2023] The Texas Instruments OPA928EVM Evaluation module is a four-layer PCB in a Rogers 4350B and FR-4 hybrid stack. The EVM is based on an OPA928 36V nanoampere-level, input-bias current operational amplifier optimized for very low current and high impedance applications. The OPA928EVM's internal ESD protection structure and unique package pin allocation isolate input from output and power pins. The i ...

2023-03 Power Murata

[Mar 14 2023] Murata Power Solutions MGN1 DC-DC converter is ideal for powering the high side and low side door drive circuits of GaN in bridge circuits. These converters are designed with optimized output voltage to meet leading GaN device requirements and bring optimal system efficiency. Industrial grade temperature rating and structure, so that long service life, high reliability. The output power of MGN1 D ...

2023-03 Power Texas Instruments

[Mar 13 2023] The Texas Instruments TLV320AIC3104-Q1 Low power stereo audio codec features a stereo headphone amplifier as well as multiple inputs and outputs that can be programmed in either single-ended or fully differential configurations. The device has extensive register-based power control capabilities that enable stereo 48kHz DAC playback as low as 14mW via a 3.3V analog power supply, making it ideal fo ...

2023-03 Sensors Skyworks Solutions

[Mar 13 2023] Skyworks Solutions OLC449 optical coupler is an unsealed surface mounted optical coupler for radiation-resistant phototransistors. The optical coupler operates at 50mA continuous collector current and 40mA average input current. The optical coupler consists of an LED and N-P-N silicon phototransistor, which is electrically isolated but optically coupled within an unsealed six-pin lead-free chip c ...
