Technology Articles

2023-03 Power Texas Instruments

[Mar 13 2023] The Texas Instruments MCT8329A Three-phase brush grid driver provides a single-chip, code-free sensorless ladder solution for applications requiring high operating speeds or very fast startup times. And integrates a number of protection features to protect equipment, motors and systems from failure events. The device provides three half-gate drivers, each capable of driving both high - and low-si ...

2023-03 Passive Components United Chemi-Con

[Mar 13 2023] U-blox EVK-F9P-00 Evaluation Suite is a powerful and versatile tool for evaluating the performance of high-precision positioning products. The u-blox EVK-F9P-00 kit features a built-in USB port for power and high-speed data transfer. The kit requires no external power supply. The compact size and user-friendly interface of the evaluation kit make it ideal for a variety of applications, including ...

2023-03 Power Texas Instruments

[Mar 13 2023] Texas Instruments SN74AHC245/SN74AHC245-Q1 eight-way bus transceivers are designed for asynchronous two-way communication between data buses. Control functions are implemented to minimize external timing requirements. The device supports the transfer of data from bus A to bus B, or from bus B to bus A. This transfer will depend on the logical level of the direction control (DIR) input. Output Ena ...

2023-03 Semiconductors STMicroelectronics

[Mar 12 2023] STMicroelectronics STM32H5 Arm®Cortex®-M33 32-bit MCU+FPU extends the STM32 high-performance portfolio and delivers enhanced performance and power efficiency. The STMicroelectronics STM32H5 features 128KB Flash, 32KB RAM, 25 to 64 pin WLCSP package, and LQFP profile. The series contains the Arm Cortex-M33 with DSP and floating point unit (FPU) running up to 250MHz. Features ● High performance at ...

2023-03 Semiconductors ON Semiconductor

[Mar 12 2023] ON semiconductor NVBG025N065SC1 Silicon Carbide (SiC) MOSFETs have excellent switching performance and higher reliability compared to silicon. Anson Semiconductor NVBG025N065SC1 has a low on-resistance and a compact chip size that ensures low capacitance and low gate charge. System advantages include high efficiency, fast operating frequency, high power density, low EMI, and small system size. Fe ...

2023-03 Semiconductors Texas Instruments

[Mar 12 2023] The Texas Instruments DAC63004WCSP-EVM Evaluation Module is a platform for evaluating the performance of the DAC63004W and DAC53004W in Wafer Chip level packaging (WCSP). The DAC63004 is a commercial ultra-low power, buffered voltage, current output digital-to-analog converter (DAC) available in a variety of configurations. In addition, there is an optional circuit for evaluating DAC63004W or DAC ...

2023-03 Semiconductors Texas Instruments

[Mar 12 2023] Texas Instruments CSD96416 Synchronous step-Down NexFET™ Power class is a highly optimized design for high power, high density synchronous step-down converters. The product integrates drive IC and power mosfet to complete power level switching function. This combination produces high current, high efficiency and high speed switching capabilities in a 5mm x 6mm compact package. This power level fe ...

2023-03 Power United Chemi-Con

[Mar 12 2023] U-blox XPLR-AOA-3 Bluetooth Direction Finding Exploration Kit and Reference Design includes a U-Blox-designed circuit board for Bluetooth direction finding and indoor positioning in the NINA-B4 module. The suite enables users to evaluate ANT-B10 antenna boards and U-Blox-optimized direction finding algorithms. The kit is also a comprehensive Angle of Arrival (AoA) anchor point reference design. A ...

2023-03 Power Bourns

[Mar 11 2023] Bourns AD and SD Micro Thermal Cutoff (TCO) devices are reset micro circuit breaker devices that provide advanced over temperature protection technology. These TCO devices feature a highly rated corrosion resistant bimetallic mechanism for better durability in humid environments. SD and AD TCO have non-automatic reset (self-hold function) and automatic reset (non-self-hold function). These TCO de ...

2023-03 Sensors Molex

[Mar 11 2023] Molex EXTreme Guardian Plug-in Side Cable assemblies are clad molded cable assemblies available in a variety of circuit sizes and lengths for optimal design flexibility. These cable assemblies provide robust strain relief in connectors and cable interfaces and are adaptable to various design configurations. The EXTreme Guardian Plug-in cable assembly features polarized plug geometry and locking t ...

2023-03 Semiconductors Texas Instruments

[Mar 11 2023] Texas Instruments TLVM13610EVM Evaluation module is configured to evaluate TLVM13610 operations. The TLVM13610 is an easy-to-use synchronous step-down module with an output voltage range of 1V to 9V. The device provides up to 8A output current. In addition to evaluating the electrical performance of the TLVM13610, the TLVM13610EVM can be used as an example of the circuit design and layout of the ...

2023-03 Semiconductors Microchip Technology

[Mar 11 2023] Microchip Technology PIC18-Q71 28/40/44/48 pin microcontroller designed for high bandwidth mixed signal and sensor applications. The PIC18-Q71 MCU is well suited for use in the lighting, motor control, and medical segments. And an 8-bit virtual port module can connect digital peripherals without using external pins. The analog focused Microchip PIC18-Q71 MCU consists of a 12-bit differential ADC ...
