Technology Articles

2023-03 Power ECS

[Mar 23 2023] ECS ECS-TXO-TX20CSMV4 MultiVolt Temperature Compensated Crystal Oscillator (TCXO) provides 1.7V to 3.6V MultiVolt capability and stabilizes critical applications using analog compensation. These shear sine wave SMD TCXOs are compatible with 1.8V, 2.5V, or 3.3V power supplies and offer frequency ranges from 10MHz to 52MHz, 10KΩ/10pF output loads, ±1ppm frequency tolerance, and ±0.5ppm or ±1.5ppm f ...

2023-03 Semiconductors Analog Devices

[Mar 23 2023] Analog Devices AD4129-8 16-Bit Sigma-Delta Analog-to-Digital Converter (ADC) is an ultra-low power high-precision measurement solution for low bandwidth battery-operated applications. The fully integrated analog front end (AFE) includes a multiplexer for up to 16 single-ended or eight differential inputs, a programmable gain amplifier (PGA), and 16-bit sigma-delta (Σ-Δ) ADC, on-chip reference and ...

2023-03 Semiconductors Analog Devices

[Mar 23 2023] Analog Devices ADPA7002 power amplifier is a Gallium arsenide (GaAs), pseudocrystalline High electron mobility transistor (pHEMT), monolithic microwave integrated circuit (MMIC), 28dBm (1/2W) amplifier. A 6mm x 6mm ceramic leadless chip with a heat sink (LCC_HS) provides low thermal resistance and is compatible with surface mount manufacturing techniques. The ADPA7002 integrates a temperature com ...

2023-03 Semiconductors Microchip Technology

[Mar 23 2023] Microchip Technology AVR64EA48 Curiosity Nano Evaluation Kit (EV66E56A) is a hardware platform for evaluating AVR®EA family microcontrollers. The board is mounted with AVR64EA48 microcontroller. The board is supported by the MPLAB®X IDE and Microchip Studio for easy access to AVR64EA48's features to explore how the device can be integrated into custom designs. The Huggies Nano series evaluation B ...

2023-03 Power ECS

[Mar 23 2023] The ECS ETXO-L33CL ECSpressCON Low Voltage Differential Signal (LVDS) temperature compensated Crystal Oscillator (TCXO) has low jitter, low current and a typical supply voltage of 3.3V. These surface mount oscillators are available in a frequency range of 10MHz to 1500MHz, with input currents of 25mA to 36mA, and package sizes of 3.2mm x 2.5mm x 1.6mm. Additional features include frequency config ...

2023-03 Optoelectronics Trinamic Motion Control GmbH

[Mar 22 2023] Trinamic TMC2210 stepper motor driver ic provides configuration options with encapsulated pins and additional diagnostic output. The TMC2210 integrates an advanced stepper motor driver based on a 256 microstep built-in indexer and two fully integrated 36V, 3.0A(Max)h Bridges as well as non-dissipative integrated current sensing (ICS). The Trinamic TMC2210 Stepper motor Drive ic features a Stealth ...

2023-03 Power Texas Instruments

[Mar 22 2023] SN74TVC3010 provides 11 parallel NMOS pass transistors with a common gate. The low on-resistance of the switch allows connections to be made with minimal propagation delay. The device can be used as a 10-bit switch with the grid cascaded together to form a reference transistor. The low voltage end of each pass transistor is limited to the voltage range set by the reference transistor. This is don ...

2023-03 Power Diodes Incorporated

[Mar 22 2023] Diode PAM8906 Piezoelectric Sound Driver offers a built-in boost converter capable of driving piezoelectric sound with up to 36VPP output. The PAM8906 offers an integrated boost converter for an optimized solution with higher sound output (SPL) for greater sound output and lower static current, as well as an automatic on/off function for extended battery run time. The device is ideal for battery ...

2023-03 Power Maxim Integrated

[Mar 22 2023] Evaluation kit helps evaluate the TMC2210 stepper motor driver ic. The TMC2210-Eval-Kit consists of an MCU board Landungsbruecke, an Eselsbruecke, and a TMC2210-EVAL driver board. The toolkit provides a quick and easy start while supporting full access to all registers, functions, and diagnostics. All signals between the MCU and TMC2210 can be diagnosed by the probe on the bridge board. The TMC22 ...

2023-03 Power Texas Instruments

[Mar 22 2023] The LM3940 is a 1-A low voltage regulator designed to deliver 3.3V from a 5v power supply. The LM3940 is ideal for systems that include both 5v and 3.3v logic, with the main power supplied by the 5v bus. Because the LM3940 is a true low-drop regulator, it can keep its 3.3V output down to 4.5V while regulating the input. The LM3940's TO-220 package means that full 1 A load current can be delivered ...

2023-03 Power MaxLinear, Inc.

[Mar 21 2023] The SPX5205 is a positive regulator with extremely low step-down, output noise, and ground current (750μA at 100mA). The VOUT has a tolerance of less than 1% and is temperature compensated. Fixed output voltages 1.8V, 3.0V, 3.3V and 5.0V and an adjustable version in a small 5-pin SOT-23 package. Other key features include zero off mode current, reverse battery protection, hot shutdown and current ...

2023-03 Power Diodes Incorporated

[Mar 21 2023] AP2121 series is a positive voltage stabilized ic manufactured by CMOS process. Each IC includes a voltage reference, an error amplifier, a resistance network for setting the output voltage, a current limiting circuit for current protection, and a chip enable circuit (5-pin products only). The AP2121 series is available in 1.2V, 1.3V, 1.5V, 1.8V, 2.5V, 2.8V, 2.8V, 3.0V, 3.2V and 3.3V versions. Th ...
