Technology Articles

2022-11 Optoelectronics Amphenol Advanced Sensors

[Nov 14 2022] Ampleon's CLL3H0914L-700 and CLL3H0914LS-700 are 700 W internally pre-matched RF gallium nitride-silicon Carbide HEMT power transistors available in the frequency range from 0.9 GHz to 1.4 GHz. These devices offer excellent efficiency, heat resistance and robustness for both short and long pulse applications. The CLL3H0914L-700 and CLL3H0914LS-700 can withstand a load mismatch corresponding to VS ...

2022-11 Optoelectronics 3M

[Nov 14 2022] 3M's polycarbonate carrier tape can be used in a range of precision-manufactured designs and solutions to help minimize chip migration and cracking and help reduce pickup failures. The size of the carrier bag has decreased dramatically in less than a decade. With the growing demand for smaller, thinner components and multi-chip stacks, as well as the need for individual chip tracking, true succes ...

2022-11 Power Panasonic

[Nov 14 2022] Panasonic's AMG88x543 Grid-EYE wide-angle infrared array sensor features a high resolution 8x 8 pixels, with a total of 64 pixels for temperature distribution. These 90° sensors provide a digital output I²C external interface for detecting heat presence, direction, and temperature values. The built-in lens has a wider viewing Angle of 90° and uses MEMS thermoelectric reactor technology and compac ...

2022-11 Sensors Richtek USA Inc.

[Nov 13 2022] The RT1718S is a highly integrated TCPC controller in a WQFN-32L 4x4 package. Includes IEC-61000-4-2 ESD protection unit for CC/SBU/DP/DM. The RT1718S integrates multiple high-voltage protection switches from the high-voltage VBUS SBU1/SBU2/DP/DM, reaching adjacent pins. The AMR of the SBU OVP switch is 24V. The high voltage USB 2.0 switch also supports high voltage DCP and fast charging protocol ...

2022-11 Semiconductors Microchip Technology

[Nov 13 2022] Designed for operation in harsh conditions and extreme environments, Microchip's PIC32MZ-W1 Wi-Fi® SoC and Module Series of Pictures delivers industrial-grade features, robust Wi-Fi connectivity, and advanced security. The series features PIC32MZ-W1, a high performance 200 MHz microcontroller (MCU) that integrates excellent low power Wi-Fi connectivity and high performance encryption acceleration ...

2022-11 Semiconductors Bourns

[Nov 13 2022] The Bourns SRR1050HA series of shielded power inductors uses a ferrite core/ferrite shield design to achieve low magnetic field radiation, ideal for applications requiring low noise operating environments. These inductors are further assembled with U-shaped clamp terminals to enhance the mechanical strength of the component and mounting support. The SRR1050HA series inductors comply with AEC-Q200 ...

2022-11 Semiconductors TDK

[Nov 13 2022] TDK EPCOS B78302A series compact transformers with innovative E5 cores are suitable for ultrasonic applications. They consist of three types, with conversion ratios between 1:1:10.8 and 1:1:15.3. Depending on the type, these SMD transformers provide inductance values from 2 mH to 4 mH. They are suitable for frequencies from 50 kHz to 300 kHz. These AEC-Q200 compliant components are very compact i ...

2022-11 Semiconductors Analog Devices

[Nov 13 2022] Analog Devices' MAX78002 is an AI MCU that enables neural networks to execute at ultra-low power, at the edge of the Internet of Things. The device comes in a 144 CSBGA, 12 mm x 12 mm, 0.8mm pitch package. And combines the most energy-efficient AI processing with Analog Devices' proven ultra-low power MCU. Hardware-based CNN accelerators enable battery-powered applications to perform AI reasoning ...

2022-11 Optoelectronics GC Electronics

[Nov 13 2022] GCT further expanded its USB product range with the introduction of the elevated USB Type-C socket USB4800.the surface mount USB4800 features 16 pins to meet USB 2.0 specifications for power and data, and is designed with a centerline 3.5 mm above the PCB surface. A potential advantage of the elevation is the ability to use components with less than 1.6 mm of space below the connector. In additio ...

2022-11 Semiconductors Microchip Technology

[Nov 12 2022] Microchip's PIC32CX-BZ2 series is a universal, low-cost, 32-bit microcontroller (MCU) family of devices that support multi-protocol wireless interfaces (Bluetooth and Zigbee), hardware-based security accelerators, transceivers, and power management units. The WBZ45 module is a series of fully RF-certified wireless modules containing the PIC32CX-BZ2 wireless MCU with PCB antenna and U.F.L connecto ...

2022-11 Semiconductors Microchip Technology

[Nov 12 2022] The TN2130 low-threshold, enhanced mode (normally off) transistor uses a vertical DMOS structure and a mature silicon gate manufacturing process. This combination results in a device with the power processing capabilities of a bipolar transistor and the high input impedance and positive temperature coefficient inherent in MOS devices. The device has all the characteristics of the MOS structure wi ...

2022-11 Power ECS

[Nov 12 2022] The ECS-3225MVQ series comes from ECS and is an HCMOS AEC-Q200 compliant surface mount oscillator in a ceramic 3.2mm x 2.5mm x 1.0mm industry standard package. These oscillators are MultiVolt capable and work on power supplies compatible with + 1.8V, + 2.5V, + 3.0V or + 3.3V. They have a wide automotive operating temperature range of -40ºC to 105ºC and a standard industrial temperature range of - ...
