Technology Articles

2022-11 Semiconductors ON Semiconductor

[Nov 20 2022] The onsemi NCP1623 Critical On-mode (CrM) power factor controller is designed to drive the PFC boost stage. The NCP1623 is based on an innovative valley synchronous frequency reentry (VSFF) method that operates in critical on-off mode (CrM) until the power drops below the threshold level. As the load attenuates and frequency retreats. The PFC controller enters discontinuous on-off mode (DCM) and ...

2022-11 Power UDOO

[Nov 20 2022] U-blox SAM-M10Q Standard Precision GNSS antenna module is a patch antenna module based on the ultra-low power u-blox M10 GNSS platform. The platform supports simultaneous reception of four GNSS systems (GPS, GLONASS, Galileo and Beidou) and provides excellent sensitivity/fast acquisition for all L1 GNSS systems. Power consumption as low as 37mW in continuous tracking mode, with four parallel GNSS ...

2022-11 Semiconductors Infineon Technologies

[Nov 20 2022] Infineon Technologies ICC80QSG Single-stage Flyback Controller IC is a PWM controller for flyback topologies operating in quasi-resonant mode and Valley switching intermittent on-off mode (DCM). The ICC80QSG IC is specifically designed for battery charger applications to meet the required performance and achieve high power transfer efficiency over a wide operating range. The ICC80QSG single-stage ...

2022-11 Semiconductors Renesas Electronics America

[Nov 19 2022] Renesas Electronics RZ/N2L multi-protocol microprocessor is an LSI optimized to simplify the implementation of industrial Ethernet and TSN networks. The RZ/N2L MPU uses an Arm Cortex-R52 core with a maximum operating frequency of 400MHz and a tightly coupled memory (256KB). The device integrates a 3-port Gigabit Ethernet switch that supports the next generation networking standard TSN, as well as ...

2022-11 Semiconductors Renesas Electronics America

[Nov 19 2022] The Renesas Electronics RZ/N family of microprocessors (MPU) is an Arm® based scalable and high-performance communications device that supports multiple industrial networking protocols and redundant networking technologies on a single device. To simplify protocol implementation, the RZ/N series has a unified protocol communication abstraction layer that allows users to quickly switch from one pro ...

2022-11 Semiconductors Diodes Incorporated

[Nov 19 2022] Diodes Incorporated AP33510 Quasi-resonant Flyback GAN controllers are specifically designed for off-line flyback power supplies that require low standby power consumption, high power density, and full protection. The device operates in QR mode at full load to support switching events at drain-source valley values, minimizing switching losses. The internal limit switch frequency of the AP33510 is ...

2022-11 Semiconductors Analog Devices

[Nov 19 2022] Analog Devices Inc. ADL8105 low noise amplifiers operate in the frequency range of 5GHz to 20GHz. Adopt 2mm x 2mm, 8 pin, in line with RoHS instruction package. The ADL8105 GaAs, MMIC, pHEMT, and low noise broadband amplifiers typically have gains of 27dB in the frequency range of 12GHz to 17GHz. In addition, the device has a typical noise factor of 1.8dB (12GHz to 17GHz), a typical output third- ...

2022-11 Semiconductors Microchip Technology

[Nov 19 2022] Microchip Technology SAM G55 Audio Curiosity Development Board (EV78Y10A) is a demonstration and development platform for audio applications based on SAM G55 microcontrollers. The SAM G55 MCU is a high performance low power device based on a 320-bit ARM Cortex-M4 RISC processor with an FPU (floating point unit). The SAM G55 MCU operates at a maximum speed of 120MHz, with 512KB flash memory and up ...

2022-11 Semiconductors NXP

[Nov 19 2022] The NXP Semiconductors RD33775ACNCEVB evaluation board uses a hardware reference design for a centralized battery monitoring unit that CAN communicate directly via CAN or CAN FD. RD33775ACNCEVB features an MC33665A gateway router that transmits TPL messages from CAN or CAN FD to four different TPL ports. The NXP MC33775A ASIL D Safe Battery Controller monitors the voltage and temperature of the l ...

2022-11 Semiconductors NXP

[Nov 18 2022] TEA2093TS GreenChip synchronous rectifier is a special controller IC that can perform synchronous rectification on the secondary side of asymmetric backflow and standard backflow converters. The TEA2093TS uses an adaptive gate drive to achieve maximum efficiency under any load. The TEA2093TS controller IC integrates a sensing stage and a driver stage to drive an SR MOSFET that rectifies the outpu ...

2022-11 Semiconductors Texas Instruments

[Nov 18 2022] Texas Instruments TUSB2E11 The USB 2.0 eUSB2 repeater is designed to support both device and host modes. TUSB2E11 supports USB low speed (LS), full speed (FS), and high speed (HS) signals. The device features a number of patented designs that provide strong interoperability, optimal performance and power. For systems without an I2C interface, the TI TUSB2E11 USB 2.0 eUSB2 repeater offers eight se ...

2022-11 Sensors Texas Instruments

[Nov 18 2022] Texas Instruments TPS7A15 LDO regulators provide excellent transient response and 400mA pull current with excellent AC performance (load and line transient response). It is designed for use in space constrained applications with a subminiature 0.71mm × 1.0mm, 6 convex point DSBGA package. The device has an input voltage range of 0.7V to 2.2V and an output range of 0.5V to 2.05V, providing very hi ...
