Technology Articles

2022-11 Sensors Nuvoton Technology

[Nov 9 2022] Nuvoton's NuMicro ML56 series of low-power microcontrollers are built with a 1T 8051 core, embedded 64KB flash memory and 4KB SRAM, built-in touch-sensitive buttons, and LCD drivers running at frequencies up to 24MHz. In normal operation mode with low power operation, it can run below 100 µA/MHz. When the LCD panel is on, the power off current is less than 2 µA. The ML56 series has an operating v ...

2022-11 Sensors Amphenol Advanced Sensors

[Nov 9 2022] Made from Amphenol Advanced Sensors, Telaire T6793 is a miniature non-dispersive gold-plated optical component, single channel OEM CO2 sensor module for diffusion style, which has the accuracy and reliability of many large sensors on the market. It also meets the accuracy standard of CA Title 24. Telaire's T6793 has an accuracy rating of ±45 ppm plus 3% readings in the 400 ppm to 2,000 ppm measur ...

2022-11 Power ams

[Nov 9 2022] The 514 nm (± 1 nm) laser diode of ams OSRAM is a non customized standard product, which enables scientific and measurement equipment manufacturers to replace the argon ion laser traditionally used to generate 514.5 nm peak wavelength laser emission. PLT5 522FA_ Semiconductor lasers such as P-M12 are generally more cost-effective than argon ion lasers, with smaller volume, longer service life and ...

2022-11 Semiconductors STMicroelectronics

[Nov 9 2022] STMicroelectronics IPS1025HFQ is a monolithic architecture using M0T5 VIPower technology and QFN48L (8 mm x 6 mm) package. These ics are single high-voltage side switching devices that can drive capacitive, resistive, or inductive loads on one side of the ground (high-voltage side switches). The recommended operating voltage is in the range of 8.65V to 60V, but the breakdown voltage on the power ...

2022-11 Semiconductors STMicroelectronics

[Nov 9 2022] The ISM330IS is in a system-level package with a 3-axis digital accelerometer and a 3-axis digital gyroscope, high performance mode for improved performance (power consumption only 0.59 mA), and support for alway on low power features. To achieve optimal sports results in industrial and Internet of Things solutions. The ISM330IS has full-scale acceleration ranges of ±2 g, ±4 g, ±8 g, and ±16 g, a ...

2022-11 Semiconductors STMicroelectronics

[Nov 9 2022] STMicroelectronics L3751 synchronous step-down controller has a wide input voltage range of 6 V to 75 V. Because the shortest on-off time is only 40 ns, it has an extremely high voltage conversion ratio in the switching frequency range (100 kHz to 1 MHz). Diode simulation (DEM) implements a pulse jump mode that maximizes efficiency at light loads, thereby providing controlled output voltage rippl ...

2022-11 Power Diodes Incorporated

[Nov 8 2022] Diodes Incorporated PI2DPX20xx Linear ReDrivers provide transparent channel link training with ultra-low signal delay for good signal integrity and system compatibility. The PI2DPX2020 is a high-performance 1.8V linear conversion driver offering 20Gbps USB4 Type-C single-port or dual-port operation with flexible working modes and support for additional protocols, including Thunderbolt 4 and Displ ...

2022-11 Power Infineon Technologies

[Nov 8 2022] Infineon Technologies has developed EVAL-M1-IM323 evaluation board to support users to design three-phase motor drive applications using IM323. IM323 CIPOS ™ The miniature three-phase inverter module provides variable speed motor drive with high power density. Infineon EVAL-M1-IM323 is an iMOTION Part of the Modular Application Design Kit (MADK). When combined with the 20 pin interface connector ...

2022-11 Semiconductors Infineon Technologies

[Nov 8 2022] Infineon Technology KIT_ XMC72_ The EVK XMC7200 evaluation kit has an XMC7200D M.2 interface connector. XMC7200D is designed for interface based on AIROC Wi-Fi And BLUETOOTH Combined (not supported at present) radio module, Digilent dual Pmod SMIF header is used for interface HYPERBUS Storage. The header is compatible with Arduino for Arduino shielding. The Infineon KIT_ XMC72_ The EVK XMC7200 ev ...

2022-11 Connectors Bivar

[Nov 8 2022] BIVAR SGLC-LD liquid detection sealing washer lens cover is equipped with a color change leak detector to remind users of liquid intrusion and provide IP68 entry protection for the inside of the housing. SGLC-LD liquid detection sealing gasket lens cover has a dome Fresnel style panel thickness of 0.250 "(6.35mm) and a flat Fresnel style panel thickness of 0.118" (3.0mm). These lens caps are also ...

2022-11 Power Microchip Technology

[Nov 8 2022] Microchip Technology LAN8831 Gigabit Ethernet transceiver and GMII/MII/RGMII are fully integrated three speed (10BASE-T/100BASE-TX/1000BASE-T) Ethernet physical layer transceiver. The equipment is designed to transmit and receive data through standard CAT-5, CAT-5e and CAT-6 unshielded twisted pair (UTP). Microchip LAN8831 Gigabit Ethernet transceiver provides industry standard GMII/MII (Gigabit ...

2022-11 Power Monolithic Power Systems Inc.

[Nov 8 2022] Monolithic Power System (MPS) MP6527 half bridge motor driver is a 10 channel, half bridge DMOS output driver and integrated success rate mosfet. These motor drivers achieve an output current (IOUT) of up to 0.8A in the input voltage (VIN) range of 5.5V to 40V. The standard serial data interface controls ten half bridges respectively, and each half bridge has various diagnostic functions. These d ...
