Technology Articles

2022-11 Semiconductors ams

[Nov 24 2022] The ams OSRAM AS7421 64-channel NIR sensor is designed for spectrum recognition and space occupancy area analysis in consumer devices. The spectral response of AS7421 provides a wavelength of 750nm to 1050nm and equally distributed channels over the entire range. At the beginning of spectral measurement, all 64 channels are automatically processed by 16 parallel sampling ADCs with four continuous ...

2022-11 Semiconductors Renesas Electronics America

[Nov 24 2022] Renesas Electronics RAA2S425x Automotive Sensor Signal conditioner optimized for automotive pressure sensing systems. The RAA2S425x device provides highly accurate amplification and sensor-specific correction of signals in automotive xEV, EV, and FCEV pressure-sensing braking, transmission, and HVAC systems. The RAA2S425x IC features highly integrated, advanced digital and analog capabilities tha ...

2022-11 Power Monolithic Power Systems Inc.

[Nov 24 2022] Monolithic Power Supply System (MPS) MPQ7235 Automotive infrared LED driver provides a high frequency, synchronous, rectifier, step-down, switching mode LED device with integrated power mosfet. The MPQ7235 is AEC-Q100 certified and comes in a space-saving QFN-13 (2.5mm x 3mm) package that requires a minimum number of standard external components. The MPQ7235 provides 1.5A continuous output curren ...

2022-11 Semiconductors Texas Instruments

[Nov 24 2022] The Texas Instruments DRV3256-Q1 Automotive Gate Driver Unit (GDU) is a highly integrated three-phase gate driver for 48V automotive motor drive applications. The device is specifically designed to provide A gate drive current of 2A peak pull current and 2.5A peak fill current, as well as a 90V MOSFET transient overvoltage support to support high-power motor drive applications. Efficient bootstra ...

2022-11 Semiconductors Texas Instruments

[Nov 23 2022] Texas Instruments DRV8300U Three-phase Gate drivers feature three half-bridge gate drivers with a voltage of 100V, each capable of driving both a high - and low-side n-channel power MOSFET. The DRV8300UD uses an integrated bootstrap diode and an external capacitor to generate the correct gate drive voltage for a high-side MOSFET. GVDD is used to generate a gate drive voltage for a low-side MOSFET ...

2022-11 Semiconductors Texas Instruments

[Nov 23 2022] Texas Instruments LMK5B33216 Network Synchronizer and jitter eliminator are designed to meet the rigorous requirements of Ethernet-based networking applications with timing accuracy. 5ns (class D). The network synchronizer integrates three DPLLS to provide interruption-free switching. It also has jitter attenuation, programmable loop bandwidth, and no external loop filter. This feature maximizes ...

2022-11 Semiconductors Texas Instruments

[Nov 23 2022] Texas Instruments ESD341 TVS ESD Protection diode is a TVS ESD protection diode for HDMI 1.4 circuit protection. The ESD341 has the highest ESD impact dissipation rating (level 4) specified in IEC61000-4-2 international standard. The device's IO capacitance is 0.66pF (typical value), enabling high-speed interface protection up to 3.4Gbps, including support for protocols such as HDMI 1.4b. Low dyn ...

2022-11 Semiconductors Texas Instruments

[Nov 23 2022] Texas Instruments TPS22811x Load switches are a highly integrated set of power distribution solutions in a small package. The device supports the use of a minimum number of external components to control and monitor the power rail. The output conversion rate and surge current can be adjusted using an external capacitor. If the input exceeds the adjustable overvoltage threshold, the load is protec ...

2022-11 Semiconductors Renesas Electronics America

[Nov 23 2022] Renesas Electronics RZ/Five Evaluation Board suite provides a complete demonstration and development platform for RZ/ FIVE-RISC-V microprocessors. The RZ/Five MPU features a RISC-V CPU core (AX45MP single-core) of 1.0GHz and a 16-bit DDR3L/DDR4 interface. The device also includes a variety of interfaces, such as Gigabit Ethernet, CAN, and USB 2.0, making it ideal for entry level social infrastruc ...

2022-11 Semiconductors Dialog Semiconductor GmbH

[Nov 23 2022] Dialog Semiconductor SLG47115V-EVB Evaluation Board is the demonstration and development platform for the SLG47115V HVPAK mixed Signal Matrix. The SLG47115V combines mixed-signal logic and high-voltage H-bridge functionality in a tiny 2mm x 3mm QFN package. Disposable Programmable (OTP) non-volatile memory (NVM) stores user-defined solutions in the form of interconnects of internal logic, I/O pin ...

2022-11 Semiconductors Texas Instruments

[Nov 22 2022] Texas Instruments AMC22C11/AMC22C11-Q1 Isolated comparator is an isolated comparator with short response time. The open - drain output and input circuits are separated by an isolation gate. The barrier is highly resistant to magnetic field interference. It is certified to provide current isolation up to 3kVRMS in compliance with DIN EN IEC 60747-17 (VDE 0884-17) and UL1577 standards. It supports ...

2022-11 Semiconductors ON Semiconductor

[Nov 22 2022] The onsemi NCN5140BSCGEVB and NCN5140TSCGEVB evaluation boards are the demonstration and development platforms for the NCN5140S KNX System-level Package (SiP). The NCN5140S integrates the KNX transceiver and Arm® Cortex®-M0+ microcontroller along with the necessary passive components in one device. The rest of the components have high integration and low height, so it can be designed for ultra-th ...
