Technology Articles

2022-11 Semiconductors TDK-Lambda

[Nov 29 2022] The TDK-Lambda PYH200 200W single-output DC-DC converter is a 200W DC-DC converter mounted on a board, with a solid half-brick housing with silicone potty seal. The TDK-Lambda PYH200 DC-DC converter provides voltage stabilizer and current isolation output voltage. The series has a 14V to 160V (12:1) input voltage range and 3000VAC input/output (I/O) isolation strength. These DC-DC converters have ...

2022-11 Power Diodes Incorporated

[Nov 29 2022] Diodes Incorporated AP25810LQ USB Type-C DFP controller and power switch are designed to monitor USB Type-C Configuration channel (CC) wiring to determine when to connect a USB device. When connected to an upstream port (UFP) component, the AP25810LQ supplies power to the VBUS. It also delivers optional VBUS current source functionality to the UFP via a straight-through CC line. If an electronica ...

2022-11 Power Diodes Incorporated

[Nov 29 2022] Diodes Inc. AP43776 USB Type-C protocol decoder is a highly integrated dual-channel USB Type-C, PD3.1/PPS/QC5 protocol decoder. It is PPS and QC5 protocol certified by USB Type-C Power Supply Specification Revision 3.1V1.1. The device supports a full range of PPS APdos (enhanced Power data Objects) from 3.3V to 21V (voltage resolution at 20mV per step) and up to 6A current (current resolution at ...

2022-11 Sensors Sensirion AG

[Nov 29 2022] The Sensirion SHT40I-HD1B analog humidity sensor has been developed specifically for demanding industrial applications, such as refrigerators, air conditioners, and any other applications where the system is noisy and where digital solutions are not available. The SHT40I-HD1B features a 5V supply voltage, rugged housing, and enhanced ESD protection to meet the requirements of harsh operating envi ...

2022-11 Power Bosch Connected Devices and Solutions

[Nov 28 2022] The Bosch BMI323 6-axis Inertial Measurement Unit (IMU) combines accurate acceleration and angular velocity (gyroscope) measurements with a smart on-chip motion-triggered interrupt function. The 6-axis IMU integrates a 16-bit triaxial gyroscope, a 16-bit triaxial accelerometer, and a 16-bit digital temperature sensor on a single chip. The BMI323 provides fast and accurate inertial detection in al ...

2022-11 Semiconductors Apex Microtechnology

[Nov 28 2022] Apex Tool Group Weller WXsmart solder heads are designed for use in WXsmart welding systems. The welding heads are in full compliance with the IPC industry standard (IPC-TM-650 2.5.33 Electrical Stress Measurement for Manual Soldering Tools). These high performance tips provide fast, safe, easy tip exchange and clearly identified smart tips. Other features include accurate data results with tip o ...

2022-11 Semiconductors Texas Instruments

[Nov 28 2022] Texas Instruments TPS629203/TPS629203-Q1 Low IQ step-down converter is an efficient, small, flexible synchronous step-down DC-DC converter that is easy to use. The wide input voltage range of 3V to 17V supports a variety of systems powered by 12V, 5V, or 3.3V power rails, and single or multiple lithium-ion batteries. The TPS629203/TPS629203-Q1 can be configured to operate at either 2.5MHz or 1MHz ...

2022-11 Semiconductors Texas Instruments

[Nov 28 2022] Texas Instruments TPS22963/64 Load switch is a small ultra low RON load switch with controlled on-on function. The device uses a low RDSON N channel MOSFET and can operate in the input voltage range of 1V to 5.5V. It can also switch electric currents up to 3A. The integrated charge pump can bias the NMOS switch to obtain a low switching on-resistance. The switch is controlled by an ON/off input ( ...

2022-11 Semiconductors Texas Instruments

[Nov 28 2022] Texas Instruments HDC302x/ HDC302X-Q1 Digital humidity sensor is an integrated capacitive relative humidity (RH) and temperature sensor. It comes in a compact 2.5mm x 2.5mm package that provides high precision measurements over a wide power range (1.62V to 5.5V) with ultra-low power consumption. The temperature and humidity sensors are 100% tested and adjusted in an NIST-traceable production envi ...

2022-11 Semiconductors ON Semiconductor

[Nov 28 2022] The onsemi NCN26010XMNEVB Evaluation board is the demonstration and development platform for the NCN26010 Industrial Ethernet transceiver. NCN26010 A 10Mb/s IEEE 802.3CG-compliant device that includes a media access controller (MAC), a PLCA coordination sub-layer (RS), and a 10BASE-T1S PHY designed for industrial multipoint Ethernet. The NCN26010 provides all the physical layer functions required ...

2022-11 Semiconductors Diodes Incorporated

[Nov 27 2022] Diodes Incorporated AL1698K High Efficiency Dimmable LED driver is a high efficiency, high performance, high power factor, high current accuracy boost, step-boost, and flyback dimmable LED driver designed for use in three terminal bidirectional thyristor dimmable LED lamp applications. The package is SO-7. The AL1698K provides accurate output current throughout the line and load regulation range. ...

2022-11 Semiconductors STMicroelectronics

[Nov 27 2022] STMicroelectronics M95P32 Ultra low power 32 Mb SPI page EEPROM optimized for mobile and wearable designs. M95P32 32 Mb SPI page EEPROM features a rich feature set, ultra-low power consumption and high memory density. The device combines patented e-STM 40nm non-volatile memory (NVM) cell technology with intelligent page architecture that combines the advantages of firmware's high memory density w ...
