Technology Articles

2022-04 Sensors XMOS

[Apr 9 2022] Xsens' MTi-680 RTK GNSS/INS module is a Global Navigation Satellite System/Inertial Navigation System (GNSS/INS) that supports centimeter-level accurate position data from an external RTK GNSS receiver. This module belongs to the MTi 600 series and is lightweight, robust and cost-effective. The MTi-680 supports RTK accuracy, which means it provides smooth high-frequency (400 Hz) centimeter-level ...

2022-04 Optoelectronics Maxim Integrated

[Apr 9 2022] Maxim's MAX30207 is a low-power, high-accuracy digital temperature sensor with ±0.1°C accuracy from +30°C to +50°C and ±0.3°C accuracy from -0°C to +70°C. It offers 16-bit resolution (0.005°C). The 2 mm x 2 mm x 0.75 mm package is designed with extremely low thermal mass. It can be mounted on a flexible PCB with only two conductive traces, which minimizes heat transfer from the system PCB, enabli ...

2022-04 Optoelectronics Maxim Integrated

[Apr 9 2022] Maxim's MAX16712 is a dual-output, fully integrated, high-efficiency, step-down DC/DC switching regulator. The device operates from a 2.7 V to 16 V input supply, and each output is adjustable from 0.5 V to 5.8 V. The IC can supply up to 6 A of load current per output. The two outputs can be paralleled as a single-output dual-phase regulator, supporting load currents up to 12 A. The device's switc ...

2022-04 Power Murata

[Apr 8 2022] Based on Murata's proven 3D-MEMS sensing technology, the SCL3300-D01 is a 3-axis (XYZ) inclinometer with four user-selectable measurement modes to optimize sensor performance for different applications and their requirements. This highly integrated device includes a mixed-signal ASIC for signal processing and a flexible digital interface that eliminates the need for an external ADC, reducing size ...

2022-04 Sensors Analog Devices

[Apr 8 2022] ADI's LTM4670 is a quad-channel DC/DC step-down μModule® (micromodule) regulator with 10 A per output. These outputs can be paralleled in an array to provide up to 40 A of current capacity. The package includes the switch controller, power MOSFET, inductor, and all supporting components. Each output has a voltage range of 0.5 V to VIN, operates over an input voltage range of 2.25 V to 5.5 V, and ...

2022-04 Sensors Analog Devices

[Apr 8 2022] ADI's AD4134 is a quad, low noise, simultaneous sampling, precision analog-to-digital converter (ADC) that offers outstanding functionality, performance, and ease of use. Due to its resistive input structure, it is easy to drive, eliminating the need for an external high-speed amplifier to drive the analog input. The AD4134's inherent antialiasing filter also eliminates the need for an external s ...

2022-04 Connectors 3M

[Apr 8 2022] 3M's Foil Tape 4380 is a self-winding general purpose foil backed tape incorporating a pressure sensitive acrylic adhesive. This tape is ideal for general purpose sealing, securing, splicing or masking applications that require heat or flame protection from a foil backing. Foil Tape 4380 is a general purpose foil tape consisting of a 2.0 mil very soft foil backing and a pressure sensitive acrylic ...

2022-04 Sensors EPC

[Apr 8 2022] The EPC EPC9167 GaN-based inverter reference design improves motor system performance, range, accuracy and torque while reducing overall system cost. The inverter is extremely small in size and can be integrated into the motor housing, resulting in low EMI, high density and low weight. The EPC9167KIT standard reference design board is a three-phase BLDC motor drive inverter board featuring EPC206 ...

2022-04 Sensors Infineon Technologies

[Apr 7 2022] Infineon Technologies' CYUSBS236 USB Serial Development Kit (DVK) is an easy-to-use kit that showcases the features of the Infineon CY7C65215 USB Serial Bridge Controller. The CYUSBS236 development kit is used to help evaluate the features of the CY7C65215 dual-channel USB serial bridge controller. The DVK provides two copper pads on the PCB to test the CAPSENSE™ feature, two pairs of EEPROMs to ...

2022-04 Optoelectronics Digilent, Inc.

[Apr 7 2022] Digilent's Measurement Computing MCC152 is a voltage output and digital input/output HAT (hardware attached on top) board designed for use with the Raspberry Pi. The MCC152 provides two 12-bit analog outputs with an output range of 0 V to 5 V and an output drive current of 5 mA. Both outputs can be updated simultaneously by software. It provides eight bidirectional digital bits, each of which can ...

2022-04 Optoelectronics TDK

[Apr 7 2022] TDK Corporation has developed the KCZ-DH series of common mode filters for automotive applications. This series provides noise control for automotive high-speed differential transmission signal lines and is available in a 1210 case size (1.25 mm x 1.0 mm x 0.5 mm). The increase in advanced driver assistance systems (ADAS) has led to a rapidly growing demand for forward-sensing cameras and surroun ...

2022-04 Semiconductors Texas Instruments

[Apr 7 2022] Texas Instruments' TMAG5170 is a high precision linear 3D Hall effect sensor designed for a wide range of industrial and personal electronics applications. The high level of integration provides flexibility and accuracy for a variety of position sensing systems. The device features three independent Hall sensors on the X, Y, and Z axes. The precision signal chain and integrated 12-bit ADC enable ...
