Technology Articles

2022-04 Sensors Digilent, Inc.

[Apr 11 2022] Digilent's MMC USB-1208HS-4AO USB-based high-speed DAQ device features 8 SE/4 DIFF analog inputs, 13-bit resolution, 1 MS/s sample rate, up to 4 analog outputs, 16 digital I/O and 1 32-bit counter. The device supports a software-selectable voltage range of ±5 V to ±20 V in differential mode and ±2.5 V to ±10 V and 0 V to 10 V in single-ended mode. The device is powered by USB and requires no exte ...

2022-04 Optoelectronics Digi International

[Apr 11 2022] Image of Digi 5G and 4G LTE Cellular Routers Digi 4G LTE and 5G cellular solutions provide enterprise, industrial and transportation/mobile communications backbones to reliably and securely connect people, machines and data anywhere, anytime. Our cellular routers are fully integrated solutions dedicated to supporting the most critical business needs with rapid deployment, secure edge computing ca ...

2022-04 Semiconductors Microchip Technology

[Apr 11 2022] Microchip Technology's PD70224 is a dual MOSFET based full bridge rectifier. It contains low RDS 0.16 Ω N-channel MOSFETs for higher overall efficiency and higher output power, especially when used for powered devices (PDs) in Power over Ethernet (PoE) applications. The entire driver circuit for driving the MOSFET is on-chip, including the charge pump for driving the high-side N-channel MOSFET. T ...

2022-04 Sensors Panasonic

[Apr 11 2022] Panasonic's ASQM1 and ASQMR1 series of miniature sealed snap-action switches feature silent operation, long travel sliding contacts, and are available in up to four terminal types: Solder Terminal, Slim Terminal, Fork Terminal, and Lead Type. Only the ASQM1 series are available with ultra-thin contacts. The ASQMR1 series miniature sealed snap-action switches feature built-in resistors to monitor ...

2022-04 Sensors Analog Devices

[Apr 11 2022] ADI's AD3552R family is a low-drift, ultra-fast, 16-bit precision, current output digital-to-analog converter (DAC) designed to generate multiple output voltage span ranges. It has high precision performance, lower latency, faster settling time and faster update rate. Applications can thus increase control loop bandwidth, control applications can use less system time, or run more complex algorith ...

2022-04 Semiconductors Microchip Technology

[Apr 10 2022] Microchip Technology's AVR DB family is based on a low-power AVR core, selected world-class Core Independent Peripherals (CIPs), and fully loaded with smart analog products, giving users the freedom to design tomorrow's solutions today. The family features three on-chip operational amplifiers (op amps) for unmatched signal conditioning. With its multi-voltage I/O (MVIO), the AVR DB is the perfect ...

2022-04 Power Allegro MicroSystems, LLC

[Apr 10 2022] Allegro's A4919 is designed for a wide range of industrial applications, including lawn and garden equipment and battery-operated power tools. The control input of the A4919 provides a simple solution for many motor drive applications controlled by an external microcontroller or DSP. The bootstrap capacitor provides the required battery supply voltage to the n-channel external power MOSFET. Power ...

2022-04 Passive Components Amphenol NEXUS Technologies

[Apr 10 2022] Amphenol RF offers TNC and RP-TNC cable assemblies designed for miniature coaxial cable types. These 50 Ω cable assemblies are ideal for space-constrained applications such as IoT infrastructure and consumer devices. These components provide maximum flexibility and a safe fit with ultra-miniature interfaces. Using an external panel mounted TNC/RP-TNC, miniature coaxial cable terminations can be e ...

2022-04 Sensors Nichicon

[Apr 10 2022] NI's temperature measurement systems, based on CompactDAQ hardware, help users spend less time configuring their test systems and less time in the test process. Verification and production engineers test dozens of units for each new design. They run multiple tests, describe performance, fill out data sheets, and make sure the electronic design operates correctly over a range of temperatures. Flex ...

2022-04 Semiconductors Toshiba Semiconductor and Storage

[Apr 10 2022] Toshiba's TCR3U series reduces the bias current required to operate LDO regulators at no load compared to existing products on the market. Additionally, these devices feature a bypass mode that ensures that there is no sudden increase in bias current when the input voltage drops below a preset output voltage level. Addresses a problem common to most typical LDOs. When the battery begins to drain, ...

2022-04 Sensors ams

[Apr 9 2022] ams Osram, a leading global provider of optical solutions, announced the launch of the new PLT5 522EA_Q green laser, suitable for applications such as leveling, scanning, bioscience and point projection, with higher brightness than traditional red lasers. higher, easier to use, more reliable and more cost-competitive. While the industrial performance is comparable to that of red lasers, PLT5 522E ...

2022-04 Semiconductors 3M

[Apr 9 2022] 3M's 4492 and 4496 series of double-sided tapes are closed cell polyethylene foam carrier tapes. It is designed for demanding indoor and outdoor installation and bonding applications. A notable feature is its ability to conform and bond to irregular surfaces. It has good temperature resistance and long-term durability. The 4492 Series Flexible Foam Tape is ideal for irregular surfaces, speeding u ...
