Technology Articles

2023-01 Semiconductors Infineon Technologies

[Jan 5 2023] Infineon's NLM0010 and NLM0011 are two NFC dual-mode configuration chips with pulse width modulation (PWM) outputs designed primarily for LED applications to enable NFC programming. NLM0011 is an NFC configuration chip with integrated constant lumen output (CLO) function. Both chips come with advanced features such as operation time counting and on/off counting. For the customer, no additional ef ...

2023-01 Semiconductors Texas Instruments

[Jan 5 2023] Texas Instruments' SURFACE-MOUNT-ADAPTER-EVM Evaluation Module (EVMs) allows engineers to test current, smaller comparator and amplifier packages without the need to turn a user's existing circuit board. These evaluation modules convert the most popular small packages into the familiar larger occupancy, such as the 8, 14, and 16 occupancy of SOIC, VSSOP, and TSSOP. This option saves effort and ti ...

2023-01 Semiconductors Microchip Technology

[Jan 5 2023] Microchip Technology AVR64DD 8-bit microcontrollers are based on AVR cpus with hardware multipliers that operate at clock speeds of up to 24MHz in the full power supply voltage range of 1.8V to 5.5V. AVR64DD mcu is designed to bring real-time control and multi-voltage operation to applications including industrial controls, home appliance products, automotive and Internet of Things (IoT). AVR64DD ...

2023-01 Semiconductors Analog Devices

[Jan 5 2023] Analog Devices AD-SYNCHRONA14-EBZ Multi-channel System Clock devices are independent evaluation and prototyping applications that require high precision frequency and phase control source clocks. AD-SYNCHRONA14-EBZ, based on AD9545 and HMC7044, simplifies clock allocation and multi-channel synchronization in complex systems. The device is intended to be used by trained professionals in a laborato ...

2023-01 Semiconductors Infineon Technologies

[Jan 5 2023] The Infineon Technologies TLE4971 XENSIV Magnetic Current Sensor is a high-precision miniature coreless magnetic current sensor for AC and DC measurements, featuring two fast overcurrent detection outputs and an analog interface. Infineon's sophisticated and robust monolithic Hall technology enables highly linear and accurate current measurement up to ±120A at full range. The sensor has internal ...

2023-01 Power ABLIC

[Jan 4 2023] ABLIC S-82M1A, S-82N1A, and S-82N1B battery protection ics offer longer battery life and increased security, and feature ultra-low 990nA(maximum) current consumption during operation. These devices are designed for single-cell lithium ion and lithium polymer rechargeable batteries with accuracy of up to ±15mV of overcharge detection voltage. ABLIC S-82M1A Battery Protection IC uses external curre ...

2023-01 Semiconductors Texas Instruments

[Jan 4 2023] Texas Instruments TPS56C231 12A Synchronous step-down converter is a small, efficient, synchronous step-down converter with adaptive real-time D-CAP3 control mode. No external compensation is required because the device is easy to use and requires few external components. The device is ideal for space-constrained data center applications. The TPS56C231 has competitive features including fast load ...

2023-01 Semiconductors Texas Instruments

[Jan 4 2023] Texas Instruments TMUX7236 2:1 (SPDT) 2-channel Precision switch is a complementary metal oxide semiconductor (CMOS) switch with dual-channel latched immunity in a 2:1 configuration. The device works well with dual power supplies (±5V to ±22V), single power supplies (5V to 44V), or asymmetric power supplies such as V(DD) = 12V, V(SS) = -5V. The TMUX7236 supports bidirectional analog and digital s ...

2023-01 Semiconductors Microchip Technology

[Jan 4 2023] Microchip Technology's PIC16F177x / 176x product line is designed to support the needs of high integration, low power conversion applications. These devices provide multiple independent closed-loop power channels and system management capabilities, while providing an 8-bit platform that simplifies design and helps eliminate many discrete components in the power conversion system. This family incl ...

2023-01 Semiconductors ams

[Jan 4 2023] The AMS TMF8801 is a true Direct Time of Flight (ToF) sensor system in a single modular package. It provides highly accurate depth precision detection, and measures the round-trip time of the pulse through sub nanosecond optical pulse and anti aliasing stopwatch methods. It also provides a single area detection of an object, regardless of color, reflectivity, or texture of the object. A single mo ...

2023-01 Semiconductors Texas Instruments

[Jan 4 2023] Texas Instruments UCC21737-Q1 Single Channel gate driver is an electrically isolated gate driver designed for use with SiC mosFETs and IGBTs at DC operating voltages up to 2121V with advanced protection features, best-in-class dynamic performance and robustness. The device has a peak source and convergent current up to ±10A. The input terminal is isolated from the output terminal by SiO(2) capaci ...

2023-01 Sensors IXYS

[Jan 4 2023] IXYS, Littelfuse Technology CPC1511, current limiting 1-FORMa normally open solid-state relay (SSR), replaces electromechanical equipment while improving the performance of switching applications. The 230v CPC1511 is manufactured with an optically isolated control input and an integrated monolithic mode output current. Manufactured using ICD's HVIC SOI technology, the device is an integrated powe ...
