Technology Articles

2023-02 Semiconductors Texas Instruments

[Feb 3 2023] Texas Instruments ADS1285 32-bit low power analog-to-digital converter (ADC) features a programmable gain amplifier (PGA) and a finite impulse response (FIR) filter. The ADC is designed to meet the stringent requirements of low noise precision digitization and longer battery life of seismic monitoring equipment. Low noise PGA allows direct connection of seismometers and transformer coupled hydrop ...

2023-02 Semiconductors Texas Instruments

[Feb 3 2023] Texas Instruments BQ25628/BQ25629 Battery Charger IC is a highly integrated 2A switch mode battery charge management and system power path management device for single lithium-ion and lithium polymer batteries. The solution is highly integrated with built-in current detection, loop compensation, input reverse blocking FeTs (RBFET, Q1), high-side switch FeTs (HSFET, Q2), low-side switch FeTs (LSFE ...

2023-02 Semiconductors Texas Instruments

[Feb 3 2023] Texas Instruments TPS715 LDO regulators are low-static current devices that offer the benefits of microencapsulation, a wide input voltage range, and low power operation. Designed for battery-powered applications, the TPS715 can be used as a power management accessory for low-power microcontrollers. The TI TPS715 LDO voltage regulator is available in fixed voltage and adjustable voltage versions. ...

2023-02 Power Recom Power

[Feb 3 2023] RECOM Power REC30E-Z 30W DC-DC converters provide high power density and wide 4:1 input voltage range in industry-standard 1" x 1" shielded metal housing. Even with their compact size, these REC30E-Z converters are fully specified devices with output currents up to 7A, efficiency in excess of 90%, and no minimum load. Other features include 2000VDC/1min isolation, strict conditioning, and low rip ...

2023-02 Semiconductors Noritake Company Inc.

[Feb 3 2023] Nordic Semiconductor NRF7002-DK 802.11 Wi-Fi Development Kit used to demonstrate the nRF7002 Wi-Fi 6 companion IC contains everything you need to start development on a single circuit board. Nrf7002-dk uses nRF5340 multi-protocol system-on-chip (SoC) as the host device of nRF7002. The suite supports the development of low-power Wi-Fi 6 applications that use Wi-Fi 6 features such as OFDMA, beamfor ...

2023-02 Semiconductors Diodes Incorporated

[Feb 2 2023] Diodes Incorporated AP66 synchronous DC-DC step-down converters include an adjustable switching frequency with internal compensation, the default internal frequency is 500kHz. These Ap66 converters feature current-mode control operation for easy loop stabilization and support a variety of output capacitor loads. The DC-DC step-down converter also has high integration and few external component re ...

2023-02 Sensors Honeywell Aerospace

[Feb 2 2023] The Honeywell BAS Battery-safe Aerosol sensor uses light scattering principles to detect and report thermal runaway events in lithium-ion battery packs. These sensors detect the presence and concentration of aerosols such as smoke, liquid and debris, which are early indicators of thermal runaway events in enclosed lithium-ion battery packs. The BAS Battery Safe Aerosol sensor measures and reports ...

2023-02 Power Maxim Integrated

[Feb 2 2023] Maxim Integrated MAX31334 Ultra-Low Power Real-time Clock is a timing solution with current consumption of only 70nA. The MAX31334 integrates a high-edge power on/off switch to enable ultra-low power idle mode in duty ratio applications by disconnecting tubes connected to other devices in the system. The power switch on/off duration can be controlled by a cycle interrupt source, including a count ...

2023-02 Semiconductors Infineon Technologies

[Feb 2 2023] Infineon Technologies 6ED223xS12T EiceDRIVER Level Shifted Gate Driver IC A high voltage (up to 1200V), high speed insulated gate bipolar transistor (IGBT) with three separate high-side and low-side reference output channels for three-phase applications. Proprietary HVIC and latched CMOS technology is used to achieve a robust monolithic construction. Logic input compatible with standard CMOS or T ...

2023-02 Semiconductors Texas Instruments

[Feb 2 2023] The Texas Instruments TPA3223 mono HD analog input, Class D amplifier enables efficient operation at full power, idle and standby. Important protection features are also integrated, including undervoltage, overvoltage, cycle current limitation, short circuit, clipping detection, overheating warning and shutdown, and DC speaker protection. The TPA3223 closed-loop feedback provides low distortion a ...

2023-02 Semiconductors Texas Instruments

[Feb 1 2023] Texas Instruments TPSM33625EVM Evaluation module Configuration Used to evaluate the operating status of the TPSM33625 power module. The TPSM33625EVM supports various configurations of power modules. In addition, the performance of the power regulator can be easily verified through electrical test points. This EVM is the basis for optimizing the TPSM33625 layout and component selection. The TI TPS ...

2023-02 Passive Components Texas Instruments

[Feb 1 2023] The Texas Instruments UCC14240-Q1 Regulated Automotive DC-DC module is a high isolated voltage (3kVRMS) DC/DC module designed to power IGBT or SiC grid drivers. High precision output voltages provide better channel enhancement, resulting in higher system efficiency, without overstressing the power device grid. The UCC14240-Q1 integrates transformers and DC/DC controllers with a proprietary archit ...
