The molded power inductor of CODACA has good performance and low inductance value in high-frequency applications
2022-10
Power
CEL
[Oct 17 2022] The inductance value range of CSEB-H series high current molded power inductor of CODACA is 0.05 μ H to 33 μ H, maximum 50 A high saturation, size as small as 4.3 mm x 4.3 mm x 2.0 mm. The remarkable improvement of volume and large current makes these inductors ideal for ADAS camera power supply and other power supplies requiring large current and small size. The lightweight hidden electrode desi ...
High voltage side gate driver and common drain MOSFET of Toshiba
2022-10
Semiconductors
Toshiba Semiconductor and Storage
[Oct 17 2022] Toshiba's TCK42xG grid driver series solutions solve various challenges in power multiplexing. TCK421G is the first product in this series, specially designed for 20 V lines. Power multiplexing is an important function in applications that require the main power supply to have a backup power supply or exchange between wireless and USB charging protocols. The gate driver is suitable for various MO ...

MAX98365 14 V Plug and Play Digital Class-D Amplifier of Analog Devices has highly flexible digital audio interface
2022-10
Semiconductors
Analog Devices
[Oct 16 2022] ADI's MAX98365 is a digital input class D amplifier, providing excellent class AB audio performance and class D efficiency. The digital audio interface will automatically recognize different clock schemes of Pulse Code Modulation (PCM) and Time Division Multiplexing (TDM) without I2C programming; Just provide power, LRCLK, BCLK and digital audio to generate sound. In addition, novel pin assignmen ...

STMicroelectronics Unit-gain stable two-way operational amplifier with high voltage and current capability
2022-10
Power
STMicroelectronics
[Oct 16 2022] STMicroelectronics TSB582 is a unit gain stable dual operational amplifier with high voltage and large current capabilities, which has internal protection against overheating and current overload conditions, as well as enhanced ESD and RF noise immunity. Typically, up to 200 mA is output per channel to drive low resistance inductive loads such as angle resolvers, line output cables, and piezoelec ...

STMicroelectronics' evaluation platform helps develop and test Bluetooth Low Energy applications
2022-10
Semiconductors
STMicroelectronics
[Oct 16 2022] The STMicroelectronics evaluation platform uses a low-power BlueNRG-LPS System-on-chip (SoC) that combines inertial and ambient MEMS sensors, digital MEMS microphones, and a variety of interface buttons and leds to help develop and test BLE applications. The BlueNRG-LPS features a 64 MHz, 32-bit Arm Cortex-M0+ core, 192 KB programmable flash memory, 24 KB SRAM, MPU, and a wide range of peripheral ...

Amphenol RF AUTOMATE Type-A Mini-FAKRA four-port jack is designed with a compact modular housing
2022-10
Passive Components
Ampleon
[Oct 16 2022] The AUTOMATE Type-A Mini FAKRA four port jack to four SMA plug or jack branch cable of Amphenol RF is designed based on a highly flexible TFC-302LL cable. One end of these components is provided with a bayonet type interface which is standard in the automobile industry, and the other end is provided with a safe thread coupling mechanism. This pre configured component is ideal for cameras and othe ...

3M safety helmet is designed to help protect workers from head impact, falling and falling debris
2022-10
Passive Components
3M
[Oct 16 2022] Head protection is not only a good habit, but also a requirement in the workplace. The Occupational Safety and Health Administration (OSHA) recognizes that protecting workers from potential head injuries is a key element of many safety programs, so 3M designs and produces helmets, masks, combination systems and accessories in a variety of styles and colors to meet different needs. OSHA stipulates ...

Bel Power Solutions' EOS Power FLS250 and MFLS250 series offer up to 250 W of true fanless power
2022-10
Power
Bel Power Solutions
[Oct 16 2022] The EOS Power FLS250 and MFLS250 series of Bel Power Solution are efficient and compact power supplies. They are fanless and have a rated power of up to 250 W. When air-cooled, they can provide up to 350 W. They are designed for high reliability operation from - 40 ° C to+70 ° C and have thermal shutdown characteristics to prevent damage. These power supplies are packaged in 4.5 "x 2.5" sizes wit ...

Analog Devices' MAX16602 and MAX20790 controller IC voltage Regulator chipsets offer advanced self-protection and power features
2022-10
Semiconductors
Analog Devices
[Oct 15 2022] ADI's MAX16602 and MAX20790 chipsets are more than 95% efficient and support 60 A to 800 A designs. This high current polyphase regulator chipset provides advanced self-protection and power supply features, including accurate temperature monitoring and fast overcurrent protection. The MAX16602CL8 Evaluation Kit (EV kit) is a fully assembled and tested surface mount circuit board that contains all ...

ADMV8526 1.25 GHz to 2.6 GHz Digital Tunable Bandpass Filter of Analog Devices
2022-10
Semiconductors
Analog Devices
[Oct 15 2022] The ADMV8526 of ADI is a monolithic tunable filter IC with center frequency and pass band width, which can be configured in real time through the simple serial peripheral interface (SPI) command in the system. Its compact dimensions and flexible tunability simplify the system design and shorten the engineering development time. The ADMV8526 offers the advantage of low SWaP-C (size, weight, power, ...

STMicroelectronics Industrial Digital Output expansion board provides a powerful and flexible development environment
2022-10
Semiconductors
STMicroelectronics
[Oct 15 2022] STMicroelectronics X-NUCLEO-OUT05A1 and X-NUCLEO-OUT06A1 industrial digital output expansion boards for STM32 Nucleo, Provides a powerful and flexible environment for evaluating the drive and diagnostic capabilities of IPS1025H and IPS1025H-32 single high voltage side intelligent power solid-state relays in digital output modules connected to 2.5A and 5.7A industrial loads. X-NUCLEO-OUT05A1 and X ...

TRACO Power's TMR 12WI is a high-density 12W DC/DC converter in a SIP-8 package
2022-10
Power
Traco Power
[Oct 15 2022] TRACO Power TMR 12WI series 12 W DC/DC converter has 4.73 W/cm ³ High power density, standard SIP-8 package (12 W, 0.87 "x 0.32" package). The TMR 12WI consists of 24 models, providing 4:1 input ranges of 4.5 VDC to 18 VDC, 9 VDC to 36 VDC and 18 VDC to 75 VDC, and output voltages of 3.3 V, 5 V, 12 V, 15 V, 24 V, ± 5 V, ± 12 V and ± 15 V. These isolated DC/DC converters provide up to 90% operatin ...
