Technology Articles

2022-10 Power HARTING

[Oct 28 2022] HARTING's Han HPR high-performance transformer connector (HPTC) series is specially developed for railway transformer applications. Transformer connections are subject to environmental impacts, including mechanical shock, water, oil, direct sunlight and ozone, all of which have a negative impact on the service life of the connection. The Han HPR standard allows use in harsh environments. Enclosur ...

2022-10 Sensors Hammond Manufacturing

[Oct 28 2022] Hammond's 1551W series micro plastic housing is designed to safely protect electronic equipment from outdoor environmental factors. Each housing is equipped with self tapping cap screws and replaceable silicone washers. All specifications are available with or without integrated mounting flange. Available in light grey and black, the satin textured finish and sturdy polycarbonate material make th ...

2022-10 Power Microchip Technology

[Oct 28 2022] Microchip's AVR DD series is based on the low power consumption performance of AVR architecture, with excellent core independent peripheral (CIP) selection and full load intelligent simulation product portfolio, so users can freely carry out design innovation. With its comprehensive function set, including multi voltage input/output (MVIO), AVR DD series is very suitable for complex applications, ...

2022-10 Power Analog Devices

[Oct 28 2022] ADI's LTC6563 is a low-noise four channel TIA with a bandwidth of 600 MHz. The low noise, wide linear range and low power consumption of the LTC6563 TIA are ideal for LIDAR receivers using avalanche photodiodes (APDs) and photodiodes (PDs). The amplifier has an optional 22.2 k Ω/16.7 k Ω/11.1 k Ω/5.55 k Ω transimpedance gain (RT) and 90 μ A Linear input current range. With an APD with a total inp ...

2022-10 Power Bergquist

[Oct 28 2022] Beacon EmbeddedWorks i.MX 8M Mini/Nano System Module (SoM) can help customers bring their products to market faster and reduce design risk. The multi-core architecture of NXPi.MX 8M Mini/Nano application processor provides a platform for developing a series of devices on a single hardware design. I. MX 8M Mini/Nano SoM provides security, high performance multimedia processing including 3D graphic ...

2022-10 Power Traco Power

[Oct 28 2022] TRACO Power's TRV 2M series 2 W DC/DC converters feature a compact SIP-9 package with enhanced 5000 VAC isolation for medical and industrial applications. This series is designed to protect any connected interfaces or parts for patients that comply with 2xMOPP. TRV 2M series consists of 21 models, providing 1.5:1 input range of 4.5 VDC to 7 VDC, 9.6 VDC to 14.4 VDC, 12 VDC to 18 VDC, and 19.2 VDC ...

2022-10 Power Bourns

[Oct 27 2022] Bourns Magnetics' MH1005 and MH1608-T series high current ferrite beads are compact in size and flat in shape, providing low DCR. The rated current of MH1608-T series is up to 5 A, and that of MH1005 series is up to 3 A. These ferrite beads provide an economical solution with high impedance to suppress high-frequency noise in high-density printed circuit board (PCB) components. MH1005 and MH1608- ...

2022-10 Sensors Cornell Dubilier Electronics (CDE)

[Oct 27 2022] The CHW1010 of CoreHW is a monolithic phase matched SP16T antenna switch array, and the CHW1020 is a monolithic phase matched SP8T differential antenna switch array. Both are applicable to Bluetooth AoA and AoD DF devices. The low phase mismatch between switch paths can minimize the residual error of beam direction angle calculation, thus improving the prediction positioning accuracy. A single CH ...

2022-10 Power Panasonic

[Oct 27 2022] Panasonic expanded the POSCAP conductive polymer tantalum solid capacitor product line of TPE series. The POSCAP TPE series offers more than 100 unique part numbers and is ideal for a variety of applications. The POSCAP capacitor uses sintered tantalum as the anode system, and uses the highly conductive polymer made by Panasonic's unique method as the cathode system. This makes POSCAP capacitors ...

2022-10 Power Renesas Electronics America

[Oct 27 2022] The RX140 microcontroller in the Renesas RX100 series has the highest processing performance and low power supply current. This makes them suitable for a wide range of household appliances, industrial and building automation applications. The RX140 with RXv2 core can achieve a maximum operating frequency of 48 MHz, and its performance is about twice that of the previous RX130 operating frequency ...

2022-10 Semiconductors STMicroelectronics

[Oct 27 2022] STMicroelectronics' STEVAL-ASTRA1B development suite and reference design simplify prototype development, testing and evaluation of advanced asset tracking applications such as livestock monitoring, fleet management and logistics. The kit consists of four boards (not sold separately) : STEVAL-ATRA1 (motherboard), STEVAL-ASTRA1SB (onboard system), STEVAL-ATRA1BC (expansion board), and STEVAL-ASTRA ...

2022-10 Power Littelfuse

[Oct 27 2022] Littelfuse's ISB is a personal protection device designed to meet the time current curve requirements defined in UL 943. UL 943 outlines the categories of ground fault circuit interrupters (GFCIs) specifically used in industrial facilities. SB5000 series ISB can be used as GFCI, special ground fault circuit breaker (SPGFCI) or equipment ground fault protection device (EGFPD). Type A GFCI has a fi ...
