Technology Articles

2022-12 Semiconductors Texas Instruments

[Dec 15 2022] Texas Instruments DRV8428 stepper motor driver is for industrial and consumer applications. The device is fully integrated, with two n-channel power MOSFET h-bridge drivers, a micro step indicator and an integrated current sensor. DRV8428 can drive 1A full size output current (depending on PCB design). Texas Instruments DRV8428 adopts an internal current detection architecture, eliminating the ne ...

2022-12 Semiconductors Analog Devices

[Dec 15 2022] Texas Instruments DRV8886 is a stepper motor driver for industrial and consumer terminal device applications. The device fully integrates two n-channel power MOSFET H-bridge drivers, microstep divider, and integrated current sensing. The DRV8886 is capable of driving up to 2 A full-scale or 1.4 A rms output currents (24 V and T(A) = 25°C, depending on the PCB design). DRV8886 uses an internal cur ...

2022-12 Semiconductors Texas Instruments

[Dec 14 2022] The Texas Instruments DRV10987 device is a three-phase sensorless 180° sinusoidal motor driver with integrated power mosFEts that can deliver up to 2a continuous drive current. The equipment is specifically designed for cost-sensitive, low noise, low number of external parts fan and pump applications. Provides current to the motor at a supply voltage as low as 6.2V. When the supply voltage is hig ...

2022-12 Semiconductors Texas Instruments

[Dec 14 2022] The Texas Instruments INA188 is a precision instrument amplifier that uses TI's proprietary automatic zeroing technology. This allows for low bias voltage, near zero bias and gain drift, excellent linearity, and extremely low noise density (12 nV/√Hz), extending to DC. INA188 is optimized to provide common-mode suppression better than 104 dB (G≥10). Superior common-mode and power rejection suppor ...

2022-12 Connectors Alliance Sensors Group

[Dec 14 2022] Alliance Sensors GHS-19 series of linear variable inductance sensors (LVIT) spring position sensors measure in QA laboratories through the dimensions of non-contact equipment design of alliance sensor groups, or position measurement is applied to factory automation systems, automobile and other industrial and commercial application testing, mil/aviation testing. The sensing elements of robot arms ...

2022-12 Semiconductors Analog Devices

[Dec 14 2022] Analog Devices' ADF5610 allows fractional n or integer n phase-locked loop (PLL) frequency synthesizers to be used with external loop filters and external reference sources. Wideband microwave voltage controlled oscillators (VCO) are designed to allow frequency operation from 7300 MHz to 14600 MHz at a single radio frequency (RF) output. A series of dividers with differential frequency outputs al ...

2022-12 Semiconductors NXP

[Dec 14 2022] NX20P0477 is a USB-c (Type-C) interface overvoltage protection solution integrated with anti-damp corrosion algorithm. The CC1/CC2 pins on the system side prevent short conversion of 28v VBUS. USB-C allows the VBUS voltage to be increased to 20 V over the power transfer protocol. Due to the mechanical twisting and sliding of the connectors, the CC1/2 pins can be shortened to VBUS because the USB- ...

2022-12 Semiconductors Texas Instruments

[Dec 14 2022] Texas Instruments' CC2564MODx module is a complete Bluetooth BR/EDR and low power HCI solution that reduces design effort, cost and time to market. The CC2564MODx module includes the 7th generation core of TI and provides a universal, product-proven solution compatible with Bluetooth 4.1. These modules are FCC certified, IC and CE certified and no prior RF experience is required to develop these ...

2022-12 Power 3M

[Dec 13 2022] 3M 25G SFP28 directly connected copper cable assembly, Series 1422, is a passive copper cable assembly, utilizing 3M two-axle cable technology. They have created a highly flexible, foldable, high-performance solution with bandwidth up to 25 Gbps for connecting servers, switches, storage, and other high-speed devices. 3M's SFP28 cable assembly (Series 1422) provides data bandwidth of up to 25 Gbps ...

2022-12 Semiconductors TDK

[Dec 13 2022] TDK Corporation's BCL322515RT series of power inductors was developed for automotive electronics and is designed to plug into power lines of automotive electronic control circuits. Recently, cars are increasingly likely to have electronic control units for information communication and autonomous driving, leading to an increase in the number of inductors used in the supply circuit in the unit. By ...

2022-12 Semiconductors Infineon Technologies

[Dec 13 2022] Infineon's 3D magnetic sensor TLV493D-A1B6 delivers accurate 3D sensing with extremely low power consumption. In its small 6-pin package, the sensor provides direct measurement of x, y, and z magnetic field components, making it ideal for measuring three-dimensional motion, linear travel, and 360° Angle rotation. The TLV493D-A1B6 combines 3-axis measurement in a small low-power package to provide ...

2022-12 Power TDK-EPCOS

[Dec 13 2022] TDK-EPCOS introduces the P27 Series EPCOS NTC ICLs with a nominal disk diameter of 27 mm and lead spacing of 7.5 mm, thus expanding the product portfolio of large NTC ICLs for industrial electronics applications. The high material density of the NTC ICLs enables an efficient capacity, high-performance design with a maximum disk thickness of 7 mm. The P27 series has very stable and reliable electr ...
