Technology Articles

2023-01 Semiconductors Vector Electronics

[Jan 13 2023] The ultra-small ANA-B4 module of u-blox is a high-performance BLE module in a very small package. Nordic Semiconductor's nRF52833 chip-based modules have an independent version of open CPU (ANNA-B402) or u-connectXpress (ANNA-B412). SiP module size is only 6.5mm x 6.5mm, including antenna. The ANNA-B4 module has an internal chip antenna for easy integration and an antenna pin for the selection of ...

2023-01 Semiconductors Texas Instruments

[Jan 12 2023] The Texas Instruments UCC27284 is an N-channel MOSFET driver with a switching node (HS) rated for 100v(Max). It allows control of two n-channel MosFeTs in topologies based on half-bridge or synchronous step-down configurations. 3a peak source and sink current have low pull-up/pull-down resistance, enabling UCC27284 to drive a high-power MOSFET with minimal switching loss during the MOSFET Miller ...

2023-01 Semiconductors Texas Instruments

[Jan 12 2023] The Texas Instruments OPA2186 Precision Operational amplifier (OP-AMP) is a low-power, 24V, track-to-rail input/output zero-drift op-amp. The maximum offset voltage is 10µV and 0.04µV/°C. The device is ideal for precision instrumentation, signal measurement and active filter applications. The low static current consumption of 90µA makes the TI OPA2186 an excellent choice for power-sensitive appli ...

2023-01 Semiconductors Abracon

[Jan 12 2023] Abracon's continuous voltage family extension provides a wide range of power supply voltages while maintaining a variety of operating temperature and stability options. The ASFLDV and ASVDV series of oscillators are simple in design. At any voltage between 1.60V and 3.60V (more common voltages are 1.8V, 2.5V, 3.0V and 3.3V), they are optimized for low power consumption while providing low RMS jit ...

2023-01 Semiconductors ECS

[Jan 12 2023] The ECSpresCON family of ECS meets more than 95 percent of current quartz oscillator requirements. This is because of its configurability and because it can be delivered directly to meet the user's precise design specifications. The ECX-L is a low-jitter, low-current, frequency-configurable, surface-mounted crystal controlled oscillator with a 2.5V or 3.3V supply voltage. ECX-L is available in a ...

2023-01 Power Diodes Incorporated

[Jan 12 2023] Diodes' AP7375 Low voltage drop (LDO) regulators have a wide input voltage range (3 V to 45 V). They feature a maximum input voltage of 45 V and an extremely low static current of 2.1 µA, making them an efficient choice for multi-battery powered devices. These devices have very fast line/load transient responses to rapid changes in input voltage and load current. They have a high PSRR of 85 dB at ...

2023-01 Semiconductors Texas Instruments

[Jan 12 2023] The Texas Instruments ADC3564 Low Noise Ultra-low Power Analog-to-digital Converter (ADC) is a 14-bit 125 msps ADC designed for low power consumption. The noise spectral density of the device is -156 DBFS /Hz, with good linear and dynamic range. The ADC3564 provides intermediate frequency sampling support for a wide range of applications. High-speed control loops benefit from a short delay of onl ...

2023-01 Semiconductors Digilent, Inc.

[Jan 11 2023] Dialight's highly reliable ultra-high strength PLCC-4 SMD LED measures 3.2mm (L) x 2.8mm (W) x 3.5mm (H) and comes with a dome lens with a 30° narrow viewing Angle. The combination of the focusing perspective and the 50 mA power supply ensures a bright and high-contrast status indication for a variety of human-machine interface (HMI) applications across all industries. Applications include, but a ...

2023-01 Semiconductors Raspberry Pi

[Jan 11 2023] Raspberry Pi's Camera Module 3 is a 12-megapixel Sony IMX708 camera module. It has improved low light sensitivity, high dynamic range (HDR) support, and electric autofocus. Camera Module 3 comes in two types, visible light and infrared sensitive (NoIR) only, and offers either standard (76 degree) or wide Angle (120 degree) lenses. This is an improvement over the Camera Module 2 (with the 8-megapi ...

2023-01 Semiconductors Renesas Electronics America

[Jan 11 2023] Renesas RL78/G15 RL78 MCU supports ambient operating temperature ranges from -40°C to +85°C, -40°C to +105°C, and -40°C to +125°C. A small 3 mm x 3 mm 8 pin package with a rich serial interface makes it suitable for a wide range of applications. The functionality of the RL78/G15 has been simplified, but still includes extensive serial interfaces, comparators, and other useful features. It has a s ...

2023-01 Semiconductors Analog Devices

[Jan 11 2023] ADI's ADXL314 is a ±200 g range, 13-bit resolution 3-axis digital accelerometer. The digital output data is in 16-bit binary complement data format and is available via the serial peripheral interface (SPI), 3-wire or 4-wire, or I2C digital interface. An integrated memory management system with a 32-stage first-in-first-out (FIFO) buffer stores data to minimize host processor activity and reduce ...

2023-01 Semiconductors Analog Devices

[Jan 11 2023] ADI's ADG1412L is a monolithic complementary metal oxide semiconductor (CMOS) device containing four individually optional switches designed using the iCMOS process. Industrial CMOS (iCMOS) is a modular manufacturing process that combines high-voltage CMOS and bipolar technology. When switching signals, the on-resistance (RON) curve is flat across the analog input range, ensuring excellent linear ...
